Factory High Efficiency Low Price Double Head Automatic Soldering Machine 4-Axis Tin Soldering Robot
Price:
3800
MOQ:
1
Delivery Time:
Negotiable
Product Description
Double Head Automatic Soldering Machine 4-Axis Tin Soldering Robot
High efficiency automatic soldering robot with dual soldering heads, designed for manufacturing plants and SMT/DIP applications.
Product Parameters
| Name | Automatic Soldering Robot | Place of Origin | ShenZhen, China |
|---|---|---|---|
| Applicable Industries | Manufacturing Plant, SMT, DIP | Key Selling Points | Automatic |
| Video outgoing-inspection | Provided | Weight | 65Kg |
| Marketing Type | New Product 2024 | Voltage | 220/110V 50~60Hz |
| Warranty period | 1 Year | Dimensions | 850*750*850mm |
| Warranty of core components | 3 Years | Solder Wire | 0.6~1.5mm solder wire |
| Core Components | PLC | Temperature Accuracy | ±3° |
| Power | 680W | Solder Feeding Speed | 1~50mm/s |
| Current | 5A | Repeat Accuracy | ±0.02mm |
Technical Specifications
| Model | ZT-HXJ041R | ZT-HXJ441-R | ZT-HXJ4411-02 | ZT-HXJ4411-02R | Fixture Customization |
|---|---|---|---|---|---|
| Solder Power | 200W | 200/400w 600W | 200/400W | 200/400/600W | Need |
| Heating Temperature Range | 0-550ºC | ||||
| Machine Axis Number | 4axis | 4axis | 4axis | 5axis | Max moving speed |
| X Axis | 400mm | 400mm | 400mm | 400mm/2X | 600mm/s |
| Y Axis | 300mm | 300mm/2Y | 300mm/2Y | 300mm/2Y | 600mm/s |
| Z Axis | 100mm | 100mm | 100mm | 100mm | 400mm/s |
| R Axis | 360° | 360° | 0 | 360° | ±0.05° Error |
| Temperature Errors | ±2° | ||||
| Tin Wire Diameter | φ0.6mm-1.5mm | ||||
| Teaching File Capacity | 256MB, up to 999 files, single file up to 1000 points | ||||
| Air Pressure | 4-5kg/cm² | ||||
| Weight(Kg) | 58Kg | 68Kg | 75Kg | 85Kg | Customized |
| Size(mm) | 600*750*850 | 800*750*850 | 850*750*850 | 1000*750*850 | To order |
Product Images
Manufacturer Profile
Shenzhen Zhongtu Automation Technology Co., Ltd. is an automation equipment enterprise integrating R&D, design, manufacturing, debugging and after-sales service.
The company specializes in tooling fixtures, hardware jigs, machining, non-standard mechanical parts processing, production line optimization solutions, automated production line equipment transformation, and non-standard automation equipment design and manufacturing.
Our products are successfully used in electronics, touch screens, LCD/LED, mobile phones, and communication electronics manufacturing fields.
Our Advantages
- We are factory manufacturers
- Reduce overall cost
- Improve automation level
- Improve informatization level
- Improve product yield
- Provide customers with the most advanced system solutions for automation equipment
Packing & Shipping
Our Services
| Pre-Sale | In Sale | After Sale |
|---|---|---|
|
|
|
Frequently Asked Questions
Who are we? We are based in Guangdong, China, starting from 2015, with 11-50 people in our office.
How can we guarantee quality? Always a pre-production sample before mass production; Always final inspection before shipment.
What can you buy from us? Soldering machine, Precision spot welding machine, Glue dispenser, Screw machine.
Why should you buy from us? With ultra professional service and skill to provide high performance but competitive price goods.
What services can we provide? Accepted Delivery Terms: FOB, CIF, EXW, FCA, CPT; Accepted Payment Currency: USD, EUR, HKD, CNY; Accepted Payment Type: T/T, PayPal, Cash.
What is your warranty? We provide 1 Year Warranty for unit machine and 3 years warranty for main board.
May I buy samples? Yes! You are welcome to place sample order to test our superior quality and service.
Are you a trading company or factory? We are professional manufacturer for automation machine since 2015.
