Single Head Dual Platform Automatic Screw Locking Machine Air Blow Feeding for PCB Assembly
Price:
Price Negotiation
MOQ:
1 Set
Delivery Time:
7-15 working days
Brand:
ZT
Product Description
Single Head Dual Platform Automatic Screw Locking Machine
Air Blow Feeding | 0.5-3.0 Nm Torque | PCB & Electronics Assembly
Product Advantages
- Air blow feeding delivers screws directly to the bit, eliminating pick-up travel time and boosting throughput.
- Single head dual platform design lets one machine alternate between two fixtures, cutting idle time without operator intervention.
- programmable torque protects delicate PCB components from over-tightening damage.
- PLC plus touch screen control stores multiple programs for fast changeover between product models.
- One unit can replace 3-5 operators, significantly reducing long-term labor cost.
Technical Specifications
| Machine Type | Single Head Dual Platform |
| Feeding Type | Air Blow |
| Screwdriver Torque | 0.5-3.0 Nm |
| Screw Size Range | M1.0-M6.0 |
| Feeding Speed | 1-2 screws/second |
| Working Area | 300mm x 300mm |
| Air Pressure | 0.4-0.6 MPa |
| Power Consumption | 100W |
Applications
Ideal for PCB assembly, consumer electronics, home appliance control boards and smart device manufacturing where small screws and high mix production are common.
Why Choose Us
ZT screw locking machines are CE and ISO 9001 certified. Each unit passes outgoing inspection and a machinery test report is provided. OEM and ODM customization are available with a 1-year warranty.
