SF21/SF24/SF26/SF27/SF28 Super Fast Rectifier Diodes Silicon Through Hole DO-15 Package
Price:
Negotiable
MOQ:
3,000 Pieces
Delivery Time:
Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays
Product Description
SUPER FAST RECTIFIER DIODES
Electronics Component
Part Number: SF21 THRU SF28
Major Parameter: Reverse Voltage: 50 to 1000 Volts
| Type | VRRM | IF | IR(25ºC) | IR(100ºC) | IR(125ºC) | VF | Trr | Outline |
| V | A | μA | uA | uA | V | nS | ||
| SF21/SF21G | 50 | 2.0 | 5.0 | 50 | 0.95 | 35 | DO-15 | |
| SF24/SF24G | 200 | 2.0 | 5.0 | 50 | 0.95 | 35 | ||
| SF26/SF26G | 400 | 2.0 | 5.0 | 50 | 1.3 | 35 | ||
| SF27/SF27G | 500 | 2.0 | 5.0 | 50 | 1.7 | 35 | ||
| SF28/SF28G | 600 | 2.0 | 5.0 | 50 | 1.7 | 35 | ||
| ES2A | 50 | 2.0 | 5.0 | 100 | 0.95 | 35 | SMA | |
| ES2D | 200 | 2.0 | 5.0 | 100 | 0.95 | 35 | ||
| ES2G | 400 | 2.0 | 5.0 | 100 | 1.3 | 35 | ||
| ES2J | 600 | 2.0 | 5.0 | 100 | 1.7 | 35 | ||
| ES2K | 800 | 2.0 | 5.0 | 100 | 1.85 | 35 | ||
| ES2AS | 50 | 2.0 | 5.0 | 100 | 1.00 | 35 | SMAF | |
| ES2DS | 200 | 2.0 | 5.0 | 100 | 1.00 | 35 | ||
| ES2GS | 400 | 2.0 | 5.0 | 100 | 1.3 | 35 | ||
| ES2JS | 600 | 2.0 | 5.0 | 100 | 1.7 | 35 |
Brand: JF
Package: DO-15 Plastic
Manufacturer: Jinan Jingheng Electronics Co., Ltd.
Features:
>Low forward voltage drop
>High current capability
>High reliability
>High surge current capability
>Lead (Pb)-free component
>Component in accordance to RoHS 2011 65 EU
>High temperature soldering guaranteed:260 C/10 seconds at terminals
Application:
Used in power supply, lighting, auto, home appliance field
