Exceptional Performance ES3J Silicon Super Fast Rectifier Diode with SMB Package
Price:
Negotiable
MOQ:
3,000 Pieces
Delivery Time:
Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays
Product Description
GLASS PASSIVATED JUNCTION SUPER FAST RECTIFIER DIODE
Electronics Component
Part Number: ES3A THRU ES3K
Major Parameter:
| Type | VRRM | IF | IR(25ºC) | IR(100ºC) | IR(125ºC) | VF | Trr | Outline |
| V | A | μA | uA | uA | V | nS | ||
| ES3A | 50 | 3.0 | 5.0 | 100 | 0.95 | 35 | SMB ( DO-214AA ) | |
| ES3G | 400 | 3.0 | 5.0 | 100 | 1.25 | 35 | ||
| ES3J | 600 | 3.0 | 5.0 | 100 | 1.7 | 35 | ||
| ES3K | 800 | 3.0 | 5.0 | 100 | 2.2 | 35 |
Brand: JF
Package: SMB /DO-214AA Plastic
Manufacturer: Jinan Jingheng Electronics Co., Ltd.
Features:
Plastic package has Underwriters Laboratory Flammability Classification 94V-0
Glass passived junction
Low power loss, high efficiency
High surge current capability
High speed switching, Low leakage
Low forward voltage drop
High current capability, High reliability
High temperature soldering guaranteed:260 C/10 seconds at terminals
Component in accordance to RoHS 2011 65 EU
Application:
Used in power supply, lighting, auto, home appliance field
