Foton Aumark 22m 4x2 Telescopic Boom Aerial Working Platform Truck High-Altitude Operation Vehicle for Sale

Name: Foton Aumark 22m 4x2 Telescopic Boom Aerial Working Platform Truck High-Altitude Operation Vehicle for Sale
Brand: Zhejiang Bioclean Machinery Technology Co., Ltd

Price Negotiable

Price: Negotiation

MOQ: 1pc

Delivery Time: Negotiable

Brand: Bioclean

Product Description

Key attributes

Condition

New

Emission Standard

Euro 2

After-sales Service Provided

Onsite Installation, Overseas Call Centers, Return and Replacement, No after-sales service, Online support, Free Spare Parts, None

Place of Origin

Zhejiang, China

Horsepower

< 150hp

Engine Capacity

< 4L

Transmission Type

Manual

Fuel Type

Diesel

Dimensions (L x W x H) (mm)

6*2.5*3meter

Brand Name

Foton Aumark

Fuel Tank Capacity

≤100L

Product name

aerial lift truck

Type

aerial working platform

Keyword

high altitude operation vehicle

Color

Customer Requirements

Driving type

4X2 4X4 6X4 8X4 10X6 Truck

Chassis brand

FOTON

Boom type

Hydraulic Straight Arm

Capacity

1-150 Ton Crane

Power

12v 24v Electric Winch

Emission standard

Euro 1/2/3/4/5

SPECIFICATION	LTEMS
OVERALL DIMENSION	Length	5995	mm
	Width	2080	mm
	Height	2760	mm
WEIGHT	Weight	4495	kg
WEIGHT	Passengers (including driver)	2	People
MAINLY TECHNICAL DATA SHEET	Bucket rated weight	200	kg
	Bucket max height	28	m
	Maximum working span	12	m
	Outrigger Lateral span	Front 4350/back4020	mm
	Outrigger Longitudinal span	3970	mm
DRIVE SPECIFICATION	Front/Rear suspension	1075/1815	mm
	Front/rear extend	0/305	mm
	Approaching/Departure Angle	19/13	°
	Max. Driving Speed	100	km/h
	Maximum grade ability	30	%

Parts description		HXE5041 JGKJ6 Truck Mounted Aerial Platform
Truck chassis		JMC JX1041TCD26 chassis
Engine		JMC JX4D30B6H, Engine power: 85KW
Cab		JMC National VI CAB,Fit 2 passages(including driver)
Work platform configuration		working platform dimension:1380x700x1100mm
Boom type		4-section polygon synchronous telescopic boom
Slewing type		360 ° continuous rotation
Frame		high strength box frame
outrigger		Front V + rear H outrigger, high-strength steel box-type outrigger, built-in pipeline
Operation		Chassis equipped with a five-handle hydraulic valve group, and the outriggers are fully hydraulical driven both horizontally and vertically.
		The truck above chassis is equipped with a load-sensitive proportional valve, which can be operated purely manually.
		Loading system with wireless handheld remote control,boom luffing, telescoping and slewing can be combined.
Controller		Equipped with intelligent controller and LCD, it can realize amplitude control, automatic throttle, load, amplitude, height display and other operation information.
