Precision Fastener Screw Cold Heading Molds for Optimal Performance
Precision Fastener Screw Cold Heading Molds
Elevate your fastener production with our precision-engineered screw cold heading molds. Designed for high-volume manufacturing, these molds deliver exceptional dimensional accuracy, superior durability, and consistent performance.
| Xincheng (Xiamen) Cemented Carbide Co., Ltd. | |||||||
| number | WC ±0.5% |
CO ±0.5% |
um |
Densityg/cm3 |
HRA |
TRSN/mm2 |
Main purpose or application |
| XG2 | 94 | 6 | 2-3 | 14.98 | 90.50 | 3000 | Stretching Rod Mould |
| XG3 | 92 | 8 | 2-3 | 14.61 | 89.30 | 3200 | |
| XG4 | 88 | 12 | 2-3 | 14.31 | 89.50 | 3450 | |
| XG5 | 88 | 12 | 2-3 | 14.30 | 88.00 | 3500 | Wear-resistant and impact-resistant molds, etc. Examples include shear punches, strong rod dies for screw fastening, etc |
| XG6 | 86 | 14 | 2-3 | 14.12 | 87.00 | 3500 | |
| XG7 | 85 | 15 | 1 | 13.85 | 89.00 | 4100 | Wear-resistant and impact-resistant molds, etc. Examples include shear punches, strong rod dies for screw fastening, etc |
| XA80 | 80 | 20 | 3-6 | 15.58 | 84.00 | 3000 | Screw Die Nut Die Six-Piece Die |
| XA90 | 78 | 22 | 6-9 | 13.39 | 82.50 | 2800 | Nut Die |
| XA95 | 75 | 25 | 6-9 | 13.12 | 81.50 | 2800 | Impact-resistant forging dies, nut dies, etc. |
| XA65 | 82 | 18 | 2-6 | 13.73 | 85.50 | 3000 | Full Tungsten Punch |
| XC90 | 75 | 25 | 2-6 | 13.00 | 83.00 | 2800 | Cap Nut Die |
| XT60 | 80 | 20 | 3-6 | 13.40 | 86.00 | 3200 | high stress |
| XC75 | 75 | 25 | 2-6 | 13.00 | 83.80 | 3000 | impact-resistant |
| XT6 | 85 | 15 | 3-6 | 13.80 | 86.20 | 3200 | Stainless Steel Screw Die Stretching and Reducing Rod |
| XT7 | 80 | 20 | 3-6 | 13.38 | 84.80 | 2900 | Stainless Steel Shaping |
| XT8 | 78 | 22 | 3-6 | 13.20 | 84.00 | 2900 | Stainless Steel Screw Die Stretching and Reducing Rod |
| XT10 | 77 | 23 | 3-6 | 13.20 | 83.50 | 2900 | Nut and Cap Nut Die |
| FT60 | 86 | 14 | 3-9 | 13.97 | 84.80 | 2690 | For Hot Extrusion Molds, Hot Forging Dies |
| FT70 | 84 | 16 | 3-9 | 13.45 | 83.50 | 2700 | |
| FT80 | 88 | 12 | 3-9 | 13.30 | 82.50 | 2500 | |
Key Benefits:
-
High Accuracy: Tight tolerances ensure every screw is formed with flawless precision.
-
Exceptional Durability: Constructed from premium materials to withstand high-pressure stamping and prolonged use.
-
Extended Tool Life: Optimized design minimizes wear and reduces maintenance downtime.
-
High-Speed Efficiency: Ideal for rapid production without sacrificing quality.
-
Customizable Solutions: Tailor-made options to meet your specific manufacturing requirements.
Upgrade your production process with our high-performance fastener screw cold heading molds for reliable, cost-effective manufacturing.
