High Permeate Municipal Water Treatment RO Membrane 8040 RO Membrane
Price:
Negotiable
MOQ:
24
Delivery Time:
3-15 work days
Brand:
Keensen
Product Description
100 PSI High Permeate Flow Water 8040 RO Membrane For Municipal Water Treatment
Usage: It is applicable to the desalination of municipal water, groundwater with salt concentration less than 1000ppm. It can be widely used in pure water preparation and related industries.
Features: It can save energy and increase economic efficiency with its advantage of extreme low working pressure.
Applications
● Groundwater, tap water treatment etc.
● Supply system for dairy and beverage production, municipal drinking water, agricultural water, 2nd pass RO feed water etc.
● Feed TDS below 1000mg/L.
Benefits
Ø High Permeability
Ø Low Operating Pressure
Ø Cost-effective
Specifications
| Model |
Active Area ft2(m2) |
Feed Spacer Thickness(mil) | Permeate Flow Rate GPD(m3/D) | Stabilized Salt Rejection (%) |
| XLP-8040 | 440(40.9) | 28 | 11000(41.6) | 99.20 |
| XLP-8040HF | 440(40.9) | 28 | 13000(49.2) | 99.00 |
Standard Test Conditions
| Solution |
Temperature (℃) |
pH |
Operating Pressure psi(MPa) |
Recovery (%) |
| 500mg/L NaCl | 25 | 7.5-8.0 | 100(0.69) | 15 |
Individual flow rate may vary±15%
Element Dimensions and Operating Limits
| Model | Length | Diameter | Permeate Tube inner Diameter | Permeate Tube Extension Length | ||||
| inch | mm | inch | mm | inch | mm | inch | mm | |
| 8040 | 40 | 1016 | 7.9 | 201 | 1.12 | 28.5 | / | / |
| 4040 | 40 | 1016 | 3.9 | 99 | 0.75 | 19.1 | 1.04 | 26.5 |
|
Maximum Operating Pressure |
600psi(4.14MPa) |
| Operating Temperature Range | 0-45℃ |
| Maximum Feed Silt Density Index (SDI15) | 5.0 |
|
Free Chlorine Tolerance |
0.1mg/L |
| pH Range,Continuous Operation | 3-10 |
| pH Range,Short-Term Cleaning | 1-13 |
| Maximum Element Pressure Drop | 15psi(0.1MPa) |
