Glory NMD100 Dispenser Notes And Media Dispenser ATM Spare Parts
Price:
Contact us
MOQ:
1 unit
Delivery Time:
It depends on the quantity of your order
Brand:
Glory/ NMD/ DeLaRue/ Triton
Product Description
Glory NMD100 Dispenser Notes And Media Dispenser ATM Spare Parts
With the lowest reject rate on the market, the Glory NMD100 guarantees maximum uptime and consistent, front or rear delivery of up to 100 banknotes per bundle. Offering up to eight cassettes, each holding up to 3000 notes, the NMD100 provides extensive functionality and flexibility for your customers wherever they are deploying your solutions.
| Speed range | 7 – 8 notes per second |
|---|---|
| Document size range | Width: 58 – 92 mm Length: 100 – 181 mm Thickness: 0.06 – 0.32 mm |
| Maximum transaction size | 100 ATM fit banknotes |
| Capacity | 1 to 8 cassettes configurable Short cassette: 240 mm or 2000 banknotes Long cassette: 340 mm or 3000 banknotes A separate reject cassette: 250 banknote |
| Connectivity | RS232C connection as standard Integrated shutter interface to control your own shutter Option: plug and play shutter |
| Power supply | 120 – 240V AC, 50/60 Hz, 3A Fitted with integrated power supply |
| Operating environment | Temperature: 5–50°C, 41–122°F Relative humidity: 10–85% non-condensing *operating time above 45 degrees should be limited to less than 10% of product life |
| Dimensions (H × W × D) | 530* × 292 × 549 mm *height shown for 2 denomination with 85 mm throat extension, for each additional denomination add 128 mm |
| Throat extensions | Standard configuration 85 mm Throat extension kits for 130, 180 and 320 mm available (for rear service only) |
| Weight (without notes) | Standard 2 denomination with cassettes: 22.2 kg/48.9 lbs Additional denominations Without cassette: 3.0 kg/6.6 lbs Short cassette (optional): 2.2 kg/4.9 lbs Long cassette (standard configuration): 2.9 kg/6.4 lbs Reject cassette (standard configuration): 2.0 kg/4.4 lbs Reject Box (optional): 1.0 kg/2.2 lbs |
| Manufacturing standards and approvals | RoHS, UL, CE, UKCA |
Based on new issue banknotes, circulated notes will reduce capacity. The performance of polymer notes may reduce at extreme temperature and humidity combinations. Specifications are subject to change without notice.
What Glory NMD100 ATM parts we can supply are as below:
| Part No. | Description |
|---|---|
| A005540 | Stack Presenter (SPF 100) |
| A004819 | Bundle Output Unit (BOU 100) |
| A004818 | Bundle Carriage Unit (BCU 100) |
| A006230 | Power Supply 150 Magnatec |
| A007302 | Power Supply 150 Roal |
| A007348 | Extention kit FS 180 |
| A007294 | Extention kit FS 130 |
| A007293 | Extention kit FS 85 |
| A007356 | Extention kit RS 130 |
| A007350 | Extention kit RS 85 |
| A003406 | Protective Cover |
| A003817 | Cover |
| A004243 | Protection SP |
| A005541 | Stack Presenter Unit Rear Service (SPR 100) |
| A004819 | Bundle Output Unit (BOU 100) |
| A004818 | Bundle Carriage Unit (BCU 100) |
| A006230 | Power Supply 150 Magnatec |
| A007302 | Power Supply 150 Roal |
| A002832 | Stack Presenter Controller |
| A006273 | Protective Cover |
| A006274 | Cover |
| A003873 | Note Qualifier Unit (NQ 100) |
| A003872 | Note Stacker Unit (NS 100) |
| A003912 | Note Diverter Unit (ND 100) |
| A004655 | Central Machine Controller incl. Coverplate (CMC 100) |
| A006500 | Frame (FR 100) |
| A005271 | Firmware 2001-03.XX |
| A004277 | Belt |
| A004082 | Belt |
| A006241 | Bracket, left |
| A004093 | DE Kit |
| A006500 | Frame (FR 100) |
| A004656 | Note Feeder Controller (NFC 100) |
| A003911 | Note Feeder Unit (NF 100) |
| A006241 | Belt |
| A006284 | Belt Cover |
| 6942111 | Screw |
| A002729 | Cable Cover |
| A002809 | Screw |
| A004168 | Can Cable NFC - NFC |
| A003203 | Power Cable NFC - NFC |
| A007399 | Screw |
| A003871 | Reject Vault RV 301 (key lock) |
| A004348 | Note Cassette NC 301 (key lock) |
| A006754 | Note Cassette NC 301 (electronic lock) |
| A003277 | Carriage motor cable |
| A004054 | BCU sensor, cable incl. Sensor |
| A003971 | BCU Reject sensor, cable incl. Sensor |
| A004054 | BCU sensor cable incl. Sensor (Front Service) |
| A002803 | BCU sensor cable incl. Sensor (Rear Service) |
| A003270 | SPC- RV connector cable |
| A003201 | Power PS - SPC cable |
| A003267 | Power PS - NSC cable |
| A003276 | Power, PS-CMC cable |
| A003200 | CAN cable CMC - SPC |
| A003263 | Puls disc cable |
| A003264 | NQ cable |
| A003266 | Communication cable CMC - NSC |
| A003266 | Communication cable CMC - NSC |
| A002897 | Com cable, with handshaking |
| A005560 | Com cable, without handshaking |
| A004168 | CAN cable, NFC-NFC |
| A003203 | Power, NFC - NFC |
| A003204 | Note Cassette connector cable |
| A007329 | BOU cable |
| A003370 | BOU exit sensor |
| A003262 | Shutter Sensor PCB |
| A007321 | Connector (female) |
| A002809 | Screw |
| 6957302 | Screw |
| A002949 | Screw |
| 6957102 | Screw |
| A002729 | Cable cover |
| A000918 | Screw |
| A002729 | Cable cover |
| A006738 | Connector (male) |
| A006284 | Protection plate |
| A006283 | Protection plate |
| 6940211 | Screw |
| A007399 | Screw |
