20L - 200L Stainless Steel Vacuum Emulsifying Machine cosmetic high shear emulsifier mixer
20L-200L Stainless Steel Vacuum Emulsifying Mixing Machine Homogenizer Mixer For Cosmetics Industries
Vacuum emulsifying mixer machine consist of Main emulsifying tank, Vacuum system, Fixed type vacuum system (OPTION), Mixing system, Homogenizer system and Heating/Cooling system. All those functions work together to produce batches of good cosmetics/chemical/food products.
Application:
Cosmetic Industry: Cream, Lotion, Lipstick, Shampoo
Food Industry: Mayonnaise, Dressing, Jam, Butter, Margarine.
Chemical Industry: Polyester, Synthetic fiber Paint
Industry: Paints, Synthetic resin paint
Others: Color, Wax, Shoe cream, Coating liquid
Specific parameter requirements of emulsifier:
| 10L emulsifying pot | Specific parameters |
| Enclosure material/thickness | 304L/3mm |
| Inner Layer Material/Thickness | 316L/3 mm |
| Sandwich material/thickness | 304L/3 mm |
| Matching water phase pot | |
| Enclosure material/thickness | 304L/3mm |
| Inner Layer Material/Thickness | 316L/3 mm |
| Sandwich material/thickness | 304L/3 mm |
| Matching oil phase pot | |
| Enclosure material/thickness | 304L/3mm |
| Inner Layer Material/Thickness | 316L/3 mm |
| Sandwich material/thickness | 304L/3 mm |
| Design capacity | 10L |
| Working capacity | 8L |
| Enclosure material/thickness | 304L/Standard |
| Inner Layer Material/Thickness | 316L/Standard |
| Sandwich material/thickness | 304L/Standard |
| Service life | Over 10 years |
| Homogenizer power | 0.55 KW |
| Homogenizer speed | 2800 |
| Homogenization mode | Upper homogenization |
| Lid opening method | Manual or electric |
| Heating method | Electric heating |
| Discharge method | Inclined discharge |
| Sandwich operating pressure | 0.3 MPa |
| Vacuum degree in the pot | -0.09 MPa |
| Overall dimensions (m) | 0.8*0.55*1.43 |
| Wearing parts | 1 year spare parts. spare parts |
| Warranty Period | More than 1 year |
| Installation and | The supplier is responsible for commissioning |
| Matching water phase pot | |
| Design capacity | 5L |
| Working capacity | 4L |
| Enclosure material/thickness | 304L/Standard |
| Inner Layer Material/Thickness | 316L/Standard |
| Sandwich material/thickness | 304L/Standard |
| Sandwich operating pressure | 0.3 MPa |
| Lid opening method | Movable lid opening |
| Heating method | Electric heating |
| Discharge method | Upper suction material |
| Stirring mode | Down stirring |
| Stirring power | 0.025 KW |
| Stirring speed | 1440r/min |
| Matching oil phase pot | |
| Design capacity | 5L |
| Working capacity | 4L |
| Enclosure material/thickness | 304L/Standard |
| Inner Layer Material/Thickness | 316L/Standard |
| Sandwich material/thickness | 304L/Standard |
| Lid opening method | Movable lid opening |
| Heating method | Electric heating |
| Discharge method | Upper suction material |
| Stirring mode | Upper (lower) stirring |
| Stirring power | 0.025 KW |
| Stirring speed | 1440r/min |
