All in One Solar LED Street Light Lamp Outdoor Ip65 Waterproof Motion Sensor with Remote Control

The 9th-generation all-in-one solar street lights (3545 G9, 3965 G9, 3980 G9) are engineered with integrated solar energy conversion, storage, and intelligent control modules. Below is a technical breakdown for engineering and procurement reference:​

1. 3545 G9 Series​
Electrical Parameters:​
Rated Power: 20W; Solar Panel: 5V/45W monocrystalline (677×347×3MM, high transmittance tempered glass cover)​
Battery: 3.2V/45Ah LiFePO4 (144Wh, BMS protection against overcharge/discharge)​
LED: 60pcs 5050SMD, 180LM/W ±10 efficacy, Ra≥70, 3000K–6500K CCT (PC diffuser for uniform light distribution)​
Performance Metrics:​
Charging Efficiency: 6–9h (under 1000W/m² irradiance); Lighting Duration: 12h/night, 2–3 rainy days backup​
Motion Sensing: 120° detection angle, 20W (100%) → 4W (20%) dimming after 15s inactivity​
Environmental Adaptability: IK08 impact resistance, IP65 ingress protection, -10℃~40℃ operating temp​
Mechanical Details: 681×351×124MM dimension, 60mm pole mounting caliber, 180° rotatable bracket (aluminum alloy housing)

2. Universal Technical Advantages​
Integrated Design: 4-in-1 (solar panel/battery/LED/controller) reduces wiring by 100%, installation time by 60%​
Longevity: LED L70 lifespan >54,000h; Battery cycle life >2500 times; Solar panel service life 20–25 years​
Compliance: Meets IEC 61215 (solar panel), IEC 62133 (battery), IP65 standards

3. Cross-Scenario Advantages​
All series feature an all-in-one design (reduces installation time by 50%), 20–25-year solar panel lifespan (long-term ROI), and 2-year warranty (risk-free procurement). They align with global sustainability goals, making them the preferred choice for green lighting projects.
