Rechargeable Lithium polymer battery cell 503759 3.7V 1200mAh for Dog Trainer
Price:
Negotiable
MOQ:
10pcs
Delivery Time:
7-10days
Brand:
RESKY
Product Description
Rechargeable Lithium Polymer Battery Cell 503759 3.7V 1200mAh for Dog Trainer
Product Specifications
| NO. | Items | Specifications |
|---|---|---|
| 1 | Batteries | 3.7V 1200mAh LiPo battery |
| 2 | Charge voltage | 4.2V |
| 3 | Nominal voltage | 3.7V |
| 4 | Nominal capacity | 1200mAh @ 0.2C Discharge |
| 5 | Charge current | Standard Charging: 0.5C Rapid charge: 1.0C |
| 6 | Standard Charging method | 0.5C CC charge to 4.2V, then CV charge till current ≤0.05C |
| 7 | Charging time | Standard: 2.75 hours (Ref.) Rapid: 2 hours (Ref.) |
| 8 | Max. charge current | 1.0C |
| 9 | Max. discharge current | 1.0C |
| 10 | Discharge cut-off voltage | 2.5V±0.25V (0.2C) |
| 11 | Operating temperature | Charging: 0°C ~45°C Discharging: 0°C ~45°C |
| 12 | Storage temperature | -10°C ~ +45°C |
| 13 | Dimension | Length: 59±0.5mm (excl. tabs) Width: 37±0.5mm Thickness: 5±0.2mm |
| 14 | Drop Test | 1m drop onto concrete twice - No fire, no leakage |
| 15 | Cycle time | ≥500 cycles |
Applications
Consumer Electronics
- Smartphones and Tablets: Primary power source enabling long battery life and compact designs
- Wearable Devices: Powers smartwatches and fitness trackers without significant weight
- Cameras: Supports high-energy operations in digital cameras including video
Medical Devices
- Portable Health Monitors: Used in heart rate monitors, glucose meters, and portable ECG machines
- Implantable Devices: Meets stringent safety standards for applications like pacemakers
