Lithium Polymer Battery Cell 602535 3.7V 4.2V 400mAh 500mAh 1.85wh Power Lipo Batteries
Price:
Negotiable
MOQ:
10pcs
Delivery Time:
7-10days
Brand:
RESKY
Product Description
Lithium Polymer Battery Cell 602535 3.7V 4.2V 400mAh 500mAh 1.85wh Power Lipo Batteries
Technical Specifications
| NO. | Items | Specifications |
|---|---|---|
| 1 | Batteries | 3.7V 500mAh LiPo battery |
| 2 | Charge voltage | 4.2V |
| 3 | Nominal voltage | 3.7V |
| 4 | Nominal capacity | 500mAh (0.2C Discharge) |
| 5 | Charge current | Standard Charging: 0.5C Rapid charge: 1.0C |
| 6 | Standard Charging method | 0.5C CC charge to 4.2V, then CV charge till current ≤0.05C |
| 7 | Charging time | Standard: 2.75 hours Rapid: 2 hours |
| 8 | Max. charge current | 1.0C |
| 9 | Max. discharge current | 1.0C |
| 10 | Discharge cut-off voltage | 2.75V (0.2C) |
| 11 | Operating temperature | Charging: 0°C ~45°C Discharging: 0°C ~45°C |
| 12 | Storage temperature | -10°C ~ +45°C |
| 13 | Dimension | Length: 35±2mm Width: 25±0.5mm Thickness: 6±0.2mm |
| 14 | Drop Test | 1m drop onto concrete twice - no fire, no leakage |
| 15 | Cycle time | ≥500 cycles |
Applications
Portable Devices:
- Laptops and Notebooks: Enables sleek, lightweight designs
- Portable Game Consoles: Supports extended gaming sessions
- E-readers: Provides long reading times on single charge
Aerospace:
- Portable Electronics: High energy density and reliability
- Satellites and Spacecraft: Meets strict safety and performance requirements
Product Features
- High security performance
- Thin thickness, adjustable thickness
- Lightweight construction
- High energy density compared to other lithium batteries
- Low internal resistance and long cycle life
- Flexible size options available
- Excellent discharge performance
Product Images
