Battery Backup Hybrid Solar Inverter 5600W Single Phase 230V With Grid Feed Prevention for OEM Orders
5600W Hybrid Solar Inverter Single Phase 230V With Battery Backup And Grid Feed Prevention
Product description:
This 5600W single-phase hybrid inverter is designed for residential and light commercial energy storage systems. It supports both on-grid and off-grid modes and allows battery charging from utility and solar simultaneously (up to 100A). With wide PV input range (90–500VDC) and anti-backflow function, it efficiently manages power usage while ensuring compliance with local grid standards. It integrates a pure sine wave inverter, MPPT solar charger, and battery management in one compact design, making it ideal for grid-tied hybrid applications.
Technical parameter
| Rated Output Power | 5600W |
| Battery Voltage | 51.2VDC |
| AC Output | 230V, 50Hz (Single Phase) |
| PV Input Voltage Range | 90V – 500VDC |
| Max PV Power | 6000W |
| Charging Current (Grid + PV) | Up to 100A |
| Anti-Reverse Feed | Yes, built-in anti-backfeed system |
| Operation Mode | Hybrid (On-grid + Off-grid Support) |
Feature Advantages:
-
Grid and solar hybrid operation for flexible energy use
-
Pure sine wave output suitable for sensitive electronics
-
100A high-efficiency dual charging capability
-
Anti-reverse current feature protects against grid feedback
-
6000W PV input power supports larger solar arrays
-
Wide 90–500V DC input range optimizes PV performance
-
Integrated MPPT and battery management in one unit
-
Compact and user-friendly design for easy installation
Product Details:
Application Scenario:
