2.5GHz High-Penetration FPV Analog Video Transmitter (VTX) | Designed for Long-Range & Stable Flying
2.5GHz High-Penetration FPV Analog Video Transmitter (VTX) | Designed for Long-Range & Stable Flying
Product Description:
This professional 2.5GHz FPV Analog Video Receiver (VRX) is the key to building a reliable long-range video transmission system. Featuring extremely high receiving sensitivity, it captures clear images even in weak signal conditions. It supports the full 2.4~2.5GHz band with 32 channels, ensuring compatibility with most mainstream transmitters in this frequency. The wide voltage input allows flexible installation on various vehicles or ground stations, making it the ideal choice for stable, long-range FPV flights.
Product Features:
-
High Sensitivity: Utilizes high-performance chips for exceptional reception sensitivity, extending range and minimizing static.
-
Full-Band Coverage: Covers the entire 2.400GHz to 2.495GHz spectrum with 32 channels for superior compatibility.
-
Wide Voltage Input: Accepts DC 10V-36V, allowing direct connection to vehicle batteries, power modules, or battery banks.
-
Strong Anti-Interference: Optimized circuit design effectively suppresses same-frequency interference for stable video in complex RF environments.
-
Plug & Play: Standard video output interfaces for direct connection to displays, goggles, or DVR devices. Easy setup.
Specification Table:
| Item | Specification |
|---|---|
| Model | 2.5G VRX |
| Frequency Range | 2.400 ~ 2.495 GHz |
| Channel Number | 32 CH |
| Receiver Sensitivity | ≤ -98 dBm (Typ.) |
| Video Output | Analog CVBS |
| Input Voltage | DC 10V - 36V |
| Connector | SMA Female (Antenna), RCA/AV Out |
| Operating Current | Approx. 120mA @ 12V |
| Dimensions | Approx. 70mm x 50mm x 20mm |
