4.9–5.8GHz 64 Channel 2.5W High Power FPV VTX Wireless Video Transmitter with IRC Tramp Control
Price:
Negotiation
MOQ:
10
Delivery Time:
5-7 work days
Brand:
Kimpok
Product Description
4.9–5.8GHz 64 Channel 2.5W High Power FPV VTX Wireless Video Transmitter
This high-power wireless video transmitter operates across a wide 4.9GHz to 5.8GHz frequency range and supports 64 channels, delivering stable and reliable video transmission for long-range and professional applications.
Product Overview
With a maximum RF output of 2.5W and support for IRC Tramp protocol, this transmitter can be configured either via software or manual button control, offering excellent flexibility for different system requirements.
Key Features
- Wide frequency coverage from 4.9GHz to 5.8GHz, including low-frequency bands
- 64 channels for multi-device and multi-pilot environments
- 6 power levels: PIT / 25 / 400 / 800 / 1500 / 2500 mW
- Supports IRC Tramp protocol for remote configuration
- Manual button control for frequency, channel, and power adjustment
- LED indicators clearly display power level, frequency band, and channel status
- Supports NTSC and PAL video formats
- Wide input voltage range for flexible power integration
Advantages
- High output power ensures long-distance and stable video transmission
- Dual configuration modes (software and manual) improve compatibility with different systems
- Low-frequency band support provides better penetration in complex environments
- Clear status indication via LED system simplifies setup and troubleshooting
- Wide voltage input allows use with various power sources and platforms
Applications
- Long-range wireless video transmission systems
- FPV racing and freestyle applications
- Industrial and professional UAV video links
- Mobile video monitoring and real-time video feedback
- OEM / ODM customized video transmission solutions
Technical Specifications
| Item | Specification |
|---|---|
| Input Voltage | DC 7-36V |
| RF Output Power | PIT / 25 / 400 / 800 / 1500 / 2500 mW |
| Current Consumption | ≤450mA @12V (800mW) ≤850mA @12V (2500mW) |
| Frequency Range | 4.9GHz - 5.8GHz |
| Channels | 64CH |
| Video Format | NTSC / PAL |
| Control Protocol | VTX (IRC Tramp) |
| Antenna Connector | MMCX |
| Configuration Method | Software & Manual Button |
| Operating Modes | Normal Mode / PIT Mode |
