Kimpok 10W 7.2G FPV VTX 64CH 6.1–7.2GHz Analog Video Transmitter IRC Tramp OSD Long Range UAV
Kimpok 10W 7.2G FPV VTX 64CH 6.1–7.2GHz Analog Video Transmitter IRC Tramp OSD Long Range UAV
Product Overview
This 10W high-power 7.2GHz FPV video transmitter is designed for professional UAV and long-range analog video transmission applications. Supporting a wide frequency range of 6.1GHz to 7.2GHz with 64 channels, it provides excellent anti-interference capability and flexible frequency selection.
With adjustable output power up to 10W and a robust CNC aluminum housing, the VTX ensures stable signal transmission, efficient heat dissipation, and reliable performance in demanding environments. It supports IRC Tramp protocol, allowing remote configuration via flight controller OSD.
Specifications
| Parameter | Specification |
|---|---|
| Frequency Range | 6100MHz – 7200MHz |
| Channels | 64CH (8 Bands × 8 Channels) |
| Output Power | 500mW / 2W / 5W / 10W |
| Modulation | FM |
| Channel Bandwidth | 8MHz |
| Input Voltage | DC 7V – 36V |
| Current Consumption | 2.6A @ 12V |
| Video Format | NTSC / PAL |
| Control Protocol | IRC Tramp (OSD Control) |
| Antenna Connector | SMA (Female Pin) |
| Operating Temperature | -10℃ ~ +65℃ |
| Dimensions | 64 × 34 × 19.5 mm |
| (Weight) | 50g (without antenna) |
| Mounting Hole | 20×20mm (M2), 30.5×30.5mm (M3) |
