AL7210 6.1–7.2 GHz 10W High-Power Video Transmitter (VTX) — 64 Channels, IRC Tramp Remote Control

[Product Introduction]
The AL7210 is a high-performance video transmitter specifically designed for ultra-long-range flight and specialized frequency requirements. Its frequency coverage spans from 6.1 GHz to 7.2 GHz, bypassing the congested traditional 5.8 GHz band to provide a cleaner signal transmission environment. Boasting a peak output power of up to 10W, this device is the ideal choice for those seeking the ultimate in video transmission range and penetration capabilities.

[Key Features]

Ultra-Wideband Support: Supports a frequency range of 6110 MHz to 7210 MHz, encompassing a total of 64 operating channels. Stepped Power

Adjustment: Supports six selectable power levels: PIT / 1W / 2.5W / 5W / 7.5W / 10W.

Dual Control Modes: Supports both manual configuration via onboard buttons and remote control via the flight controller using the IRC Tramp protocol.

Intelligent Thermal Design: Features a robust metal casing equipped with heat dissipation fins to ensure thermal stability during high-power operation.

Comprehensive Status Indication: Integrates an RGB LED indicator to clearly display power, frequency point, and frequency band status.
