Automatic Single Chain Link Fence Weaving Machine High Durability 220V/380V

Price Negotiable
Price: $5000-50000
MOQ: 1 UNIT
Delivery Time: 14-21DAYS
Brand: APBWR
Product Description

Automatic Single Chain Link Fence Machine High Durability





1.Chain Link Fence Machine Introduction



This is a high-speed crochet net machine designed for the pursuit of ultimate output. The net output length per unit time leads the industry. Equipped with a high-performance servo drive system and an ultra-low inertia precision spindle, the knitting frequency is greatly increased and is more than 50% faster than conventional models.



Push your productivity straight to the top. For large-scale projects and large-scale production customers, it means shorter delivery cycles and significantly increased average daily output value, with extremely high return on investment.



2.Chain Link Fence Machine Motor Configuration



Main servo motor : 3.8 kw
Cutting knife motor : 0.75 kw
Barrier motor : 0.75 kw
Positioning needle motor : 0.75 kw
Pull mesh motor : 0.75 kw
Mesh edge motor : 0.75 kw X 2
Roll mesh motor 0.75 kw
Mesh width adjust motor : 0.12 kw Pump motor : 0.04 kw



3. Chain Link Fence Machine Advantages:


1.Automatic adjustment of chain link fence mesh width.

2.The machine will give an alarm when the coil is disordered.
3.The cutter device is also equipped with a brake system for more accurate positioning.
4.The machine is equipped with two sets of edge system ( hook edge and twisted edge).
5.The mesh rolling system is equipped with brake device, so the wire mesh will not reverse.
6.The connecting line uses aviation plug, which is convenient for customers to install machinery.
7 .The machine adopts aluminum alloy cantilever box for operation, which is simple and convenient.
8.The machine is equipped with remote control device, which is convenient for employees to operate the machine.

4. Chain Link Fence Machine Specification

Model
APB3000
Mesh width
500-3000 mm (can be customized)
Mesh size
25-100 mm
Wire diameter
1.4-4.0 mm
Production speed
80-150 m²/h
Mesh edge
Hook edge and twisted edge ( 2 set edge system)
Machine weight
3500 KG
Mechanical dimension
5800*3600*1800 mm

5.Chain Link Fence Machine Detailed images:
