4145H Material 5000-15000psi Pressure Upper IBOP Assembly with 6 5/8" REG Connection for Top Drive Systems
Description
| Product Name: | Top Drive IBOP Assembly | Weight: | 74 Kg |
|---|---|---|---|
| Color: | Black | Material: | 4145H |
| Connection: | 6 5/8" REG | Pressure: | 5000-15000psi |
| Quality: | High Level | Machine Type: | Drilling Equipment |
| High Light: |
4145H Drilling Rig Spare Parts,IBOP Assembly Drilling Rig Spare Parts |
||
API Oilfield Varco / JH Top Drive System Upper IBOP
The IBOP Assembly is an essential well-control component designed for Top Drive drilling systems. The assembly consists of an Upper IBOP and a Lower IBOP, which work together to provide reliable pressure control during drilling operations with connected drill string sections.
Engineered to withstand high-pressure conditions from both upward and downward directions, the IBOP is available with working pressure ratings of 10,000 PSI and 15,000 PSI. The valve body bore and all internal components undergo special surface treatment to enhance corrosion resistance and extend service life in demanding drilling environments.
Technical parameters:
| Type | O.D(mm) | I.D.(mm) | Length (mm) | Connection API |
| 187-3 | 187 | 76.2 | 523 | 6 5/8REG |
| 196-3 | 195.8 | 76.2 | 523 | 6 5/8REG |
| 197-3 | 197 | 76.2 | 512 | 6 5/8REG |
| 216-3 | 216 | 3 | 600 | 6 5/8REG |
For sour service applications, Topland also offers H₂S-resistant IBOP assemblies manufactured from premium imported sulfur-resistant materials to ensure reliable performance under harsh operating conditions.
