1500 Psi Stainless Steel Pressure Vessel For Stripping Column M.D.M.T. -6℃
Stainless Steel Pressure Vessel for Stripping Column M.D.M.T. -6℃
Product Description:
The pressure rating of a stainless steel stripping column depends on several factors, including material grade, wall thickness, temperature, and design standards (e.g., ASME, PED). Below are key considerations for determining the pressure capacity:
Design Standards & Calculations
ASME BPVC Section VIII (for pressure vessels) is commonly used.
Cylindrical Shell Thickness Calculation (simplified):
t= P⋅D / (2⋅S⋅E−1.2⋅P)
= Minimum wall thickness (mm)
= Internal design pressure (bar or psi)
= Inner diameter (mm or in)
= Allowable stress (from ASME tables, e.g., ~80-120 MPa for 304SS at 100°C)
= Joint efficiency (0.7-1.0, depending on welding)
Technical Parameters:
| DENSITY | 1005 Kg/m3 |
| INSULATION/FIREPROOFING | YES |
| CAPACITY | 0.23 M3 |
| DESIGN PRESSURE | 4 Bar G |
| Certifications | ASME U Stamp, National Board R Stamp |
| Pressure Level | Low Pressure (0.1MPa≤p<1.6MPa) |
| DESIGN CODES | ASME VIII + IBC 2018 + ASCE 7+NACE |
| OPERATING TEMPERATURE | 70 ~ 95 ºC |
| Application | Stripping Coulmn |
| Pressure Rating | 1500 Psi |
Applications:
The YUHONG Pressure Vessel, originating from CHINA, is a versatile and reliable product designed for various application occasions and scenarios. Design codes such as ASME VIII, IBC 2018, ASCE 7, and NACE MR0175, this pressure vessel is suitable for a wide range of industrial uses.
- Oil & Gas / Petro and chemicals
- Chemical Processing
- Water & Wastewater Treatment
- Food & Beverage
- Medicine & Biotechnology
- Environmental & Air Pollution Control
- Specialty Applications
Customization:
Product Customization Services for Pressure Vessel:
Brand Name: YUHONG
Place of Origin: CHINA
CAPACITY: 0.23 M3
Certifications: ASME U Stamp, National Board R Stamp
M.D.M.T.: -6 ºC
DESIGN PRESSURE: 4 Bar G
DESIGN TEMPERATURE: + 150 / -6 ºC
Keywords: FITTINGS, INTERNAL SUPPORTS, STIFFENING RINGS
Support and Services:
Our Product Technical Support and Services for the Pressure Vessel product include:
- Expert troubleshooting assistance for any issues related to the pressure vessel.
- Guidance on proper installation, maintenance, and operation of the pressure vessel.
- Access to product manuals, technical documents, and instructional materials.
- Training programs for operators and maintenance personnel to ensure safe and efficient use of the pressure vessel
