ASME SA210 / SA210 GR-C Seamless Tube High Strength Carbon Steel Boiler Tube For High Temp, Superheater, Power Generation
Price:
Negotiable
MOQ:
500 KGS
Delivery Time:
Depends on order quantity
Brand:
YUHONG
Product Description
ASME SA210 / SA210 GR-C Seamless Tube High Strength Carbon Steel Boiler Tube For High Temp, Superheater, Power Generation
ASME SA210 GR-C seamless steel tube is a steel tube designed specifically for critical pressure-bearing components in high-pressure boilers, based on high strength and advanced heat treatment processes.
Through higher carbon and manganese content and precise heat treatment, it achieves significantly higher strength and creep resistance up to 649°C compared to the SA210 GR-A series.
In the fields of power plant boilers and heat exchangers, it is an important upgrade solution to replace ordinary carbon steel, reducing wall thickness and improving efficiency. Its core value lies in balancing high strength with good machinability, ensuring long-term stable operation of pressure-bearing equipment in industries such as power and chemical engineering at high temperatures. The chemical composition of ASME SA210 GR-C has strict smelting analysis requirements. Compared to the GR-A grade, its carbon and manganese content range is wider, giving the material a higher strength base.
| Chemical Composition | |
| Element | Composition (wt%) |
| Carbon (C) | ≤ 0.35 |
| Manganese (Mn) | 0.29 – 1.06 |
| Phosphorus (P) | ≤ 0.035 |
| Sulfur (S) | ≤ 0.035 |
| Silicon (Si) | ≥ 0.10 |
| Mechanical Properties | |
| Property | Value (min.) |
| Tensile Strength | ≥ 485 MPa (70 ksi) |
| Yield Strength | ≥ 275 MPa (40 ksi) |
| Elongation (in 2 in / 50 mm) | ≥ 30% |
| Hardness (Brinell) | ≤ 179 HBW (or ≤ 89 HRBW) |
Application:
• Superheaters and reheaters: Improve steam temperature and quality.
• Economizers: Preheat feedwater to improve boiler efficiency.
• Steam piping and headers: Collect and distribute steam.
• High-pressure boiler systems: Widely used in fossil fuel, nuclear, and combined cycle power plants.
• Boilers and pressure vessels: Suitable for various designs requiring reliable materials.
• General engineering applications: Includes components such as flues, safety ends, supports, and arches.
• General engineering for the oil and gas industry.
