This TEMA-compliant shell and tube heat exchanger is engineered for high-efficiency heat transfer in demanding environments such as oil & gas refining, petrochemical processing, power generation, and heavy industrial plants. Built to ASME Section VIII Div.1​ with TEMA Class R/C/B​ construction, the unit delivers reliable cooling, heating, condensation, and heat recovery under high pressure, high temperature, and corrosive service conditions.

Key Design Features

• TEMA Standard Configuration​ – BEM / AES / BEU / Floating Head / U-Tube / Fixed Tubesheet available
• ASME VIII Div.1 Pressure Boundary​ – U-Stamp capable, hydrostatic tested at 1.5× design pressure
• Corrosion-Resistant Materials​ – SA-516 Gr.70 shell, 316L stainless, duplex 2205/2507, titanium, Cu-Ni, Inconel options
• High Thermal Efficiency​ – optimized tube pitch, baffle cut and pass arrangement for low pressure drop
• Leak-Free Tube-to-Tubesheet Joints​ – expand + strength welded, PMI verified
• Easy Maintenance​ – removable bundle, accessible channel cover, spare gasket and fastener kit optional

Working Principle

Heat is transferred through the tube wall. The tube-side fluid and shell-side fluid never mix. Depending on process requirements, the unit can be configured for counter-flow, parallel flow, or cross-flow, with single-pass or multi-pass tube arrangement.

Typical Applications

• Crude oil cooling / heating in refineries
• Gas processing and separation train cooling
• Solvent recovery and reactor temperature control
• Amine treating and sour gas service
• Power plant condensers and feedwater heating
• Offshore platform heat recovery loops

Quality Assurance

Every unit is supplied with:

• Material Test Report (EN 10204 3.1)
• Hydrostatic & pneumatic test record
• RT / UT / PT / MT / PMI inspection reports
• ASME U-Stamp, PED, ABS / DNV / BV / CCS certification support
• Dimensional and surface roughness inspection on sealing faces
