Micro Motion ELITE Series Coriolis Flow and Density Meter with Smart Meter Verification 6000 psig Pressure Range and 316L Stainless Steel Construction
Price:
negotiable
MOQ:
1
Delivery Time:
on request
Brand:
Micro Motion
Product Description
Micro Motion Elite Series
Micro Motion ELITE Series Coriolis Flow and Density Meters: Peak Performance for Demanding Applications
The Micro Motion ELITE Series represents the pinnacle of Coriolis flow and density measurement technology. Engineered to excel in the most challenging environments, these meters deliver exceptional accuracy and repeatability across a wide spectrum of fluids—including liquids, gases, slurries, and multiphase flows. The ELITE Series is built to provide unwavering measurement confidence where it matters most.
Key Features & Benefits
- Unmatched Measurement Integrity: Features a uniquely designed sensor that provides superior sensitivity and long-term stability, ensuring precise data for both flow and density.
- Proactive Process Assurance: The integrated Smart Meter Verification technology offers real-time, in-process diagnostics, confirming meter health without process interruption. This enhances operational reliability and reduces maintenance costs.
- Superior Immunity & Confidence: Boasts the highest immunity to fluid properties, process noise, and environmental variables, guaranteeing dependable performance in dynamic conditions.
- Exceptional Application Versatility: Scalable design covers a broad array of needs, from hygienic and cryogenic services to high-pressure applications, offering a future-proof solution.
- Extended Operational Envelope: Supports an industry-leading temperature range from -400 °F to 662°F (-240°C to 350°C) and pressures up to 6,000 psig (414 barg), handling extreme process windows.
- Global Compliance & Approval: Comes with the industry's widest range of certifications, including CSA, ATEX, NEPSI, IECEx, IP66/67, SIL 2/3, marine approvals, and custody transfer standards, facilitating global deployment.
- Robust Material Selection: Available in 316L Stainless Steel, C-22 Nickel Alloy, and Super-Duplex materials to ensure corrosion resistance and longevity in aggressive media.
Technical Specifications
| Parameter | Specification |
|---|---|
| Liquid Accuracy / Repeatability | 0.1% - 0.05% / 0.05% - 0.025% |
| Gas Accuracy / Repeatability | 0.25% / 0.20% |
| Density Accuracy / Repeatability | 0.0005 - 0.0002 g/cc / 0.00025 - 0.0001 g/cc |
| Line Size | 1/12 inch (DN2) - 12 inch (DN300) |
| Pressure Range | Rated up to 6000 psig (414 barg) for select models |
| Temperature Range | -400°F to 662°F (-240°C to 350°C) |
| Electronics | Expansive I/O options including mA, frequency, discrete, HART, Modbus, Ethernet/IP, PROFINET, FOUNDATION Fieldbus |
| Turndown | Up to 30:1 turndown from nominal |
