433MHz 10W GaN Module for Anti Drone System
Padi Fly main business includes UAV detector module, handheld detection, backpack detection, vehicle detection, UAV accessories, etc.
--GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module.
--We provide broadband and band specific, high power RF and microwave amplifier solutions to OEM
|
Brand Name
|
PDFY
|
|
Working frequency
|
433MHz
|
|
Saturated output power
|
40±1dBm
|
|
Gain
|
42±2dB
|
|
In-band fluctuation
|
≤2.0dB
|
|
Out-of-band spurious |
9kHz~1GHz:≤-36dBm/30kHz
1GHz~12.75GHz:≤-30dBm/30KHz |
|
Input VSWR
|
≤1.5
|
|
Gain temperature stability
|
≤±1.5dB
|
|
Working voltage
|
DC+28V
|
|
Power supply monitoring interface
|
Power supply and power amplifier enabling: through the heart capacitor
|
|
Output RF port
|
SMA
|
|
Dimensions
|
29.7*131*15.5mm(excluding SMA)
|
|
Working temperature
|
-20~+55ºC
|
Our company is located in the vibrantcity of Shenzhen,known as a hub of innovation andtechnology in China.
With over 3000 square meters of plant space, we specialize in the design, development, and distribution of FPV drones along with drone countermeasure solution.
We are known for our innovation, quality, and commitment to enhancing the user experience.
Our Business Range for FPV drone accessories:
We can provide include: Image transmission, motor, carbon fiber frame, flight control, electrical regulation, antenna, remote control, propeller, charger, etc..
We also provide the industry's professional OEM and ODM technology and services.
|
Selling Units:
|
Single item
|
|
Single package size:
|
20X20X10 cm
|
|
Single gross weight:
|
0.3kg
|
|
Package Type:
|
Each piece is individually packed into a bag and then packed into a carton.
|
