2Mpa 70Mpa Hydraulic Crimping Tools Manual Hydraulic Pump 15.5KG
Manual Hydraulic Pump Hydraulic Crimping Tools
Suntech Power is a manufacturer of research,development, production and sales: Stringing Block, Hoisting Tackle,
Wire Grip, Reel Stand,Inspection Trolleys, Tightening Tools, Connector, Shackle, Lifter, Head Boards For Conductors,
Mesh Sock Joints, Powered-winch, Press-machine and other construction tools and equipment company for electric
power construction. At the same time, agents of various imported construction tools and power equipment.
Manual Hydraulic Pump Application
to provide power for the cutting tool, the hydraulic compressor,
punching machine and other construction machinery,
which is operated in the wild field in electric power, railway, rescue, construction and other industries.
Manual Hydraulic Pump Features
1. Double loop piston
2. Iron box packing
3. Use No.15 Antiwear hydraulic oil
| Item number | 16164C | 16164 | 16164A | 16164B |
| Model | CP-180 | CP-700 | CP-700A | CFP-800B |
| Type | hand | hand | hand | foot pump |
|
Max output pressure |
/ | low pressure 2Mpa | low pressure 2Mpa | low pressure 2Mpa |
| high pressure 70MPa | high pressure 70Mpa | high pressure 70Mpa | high pressure 70Mpa | |
|
Output of the oil |
/ | low pressure 13cc | low pressure 13cc | low pressure 13cc |
| high pressure 1.8cc | high pressure 2.3cc | high pressure 2.3cc | high pressure 2.3cc | |
| Oil capacity | 350cc | 900cc | 2700cc | 600cc |
|
Direction of piston |
single | double | double | double |
| Weight(KG) |
approx.N.W9.5KG G.W10.9KG |
approx.N.W9.5KG G.W10.9KG |
approx.N.W14.1KG G.W15.5KG |
approx.N.W9.8KG G.W10.8KG |
|
Measurement (LxWxH) |
340×60×120mm | 700x100x160mm | 700x100x200mm | 520x160x170mm |
| Package | paper box | paper box | paper box | paper box |
