2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm
2x(1x4) PM PLC Splitter Polarization Maintaining Fiber Splitter 1260 1650nm FC APC To MPO APC For Coherent Communication Gyroscope And Fiber Sensor
This product is a 2*(1*4) PM PLC Splitter (two sets of 1*4 polarization-maintaining PLC splitters), integrating two independent 1*4 polarization-maintaining splitter channels within a single module.
-
Dual-Group 1*4 Integration, Eight Outputs in One Module
-
Low Insertion Loss and Excellent Channel Uniformity
-
High Extinction Ratio, Strong Polarization Preservation Capability
-
High Return Loss and High Directivity, Reducing Reflection and Crosstalk
-
Wide Operating Wavelength and Environmental Adaptability
-
Compact Structure and Clear Cabling
| Parameters | Unit | Value |
|---|---|---|
| Operating Wavelength | nm | 1260~1650 |
| Test Wavelength | nm | 1550 |
| Insertion Loss | dB | ≤8.2 |
| Uniformity | dB | ≤0.8 |
| Extinction Ratio | dB | ≥18 |
| Return Loss | dB | ≥50 |
- Coherent Communication
- Fiber Optic Gyroscope
- Fiber Sensor
