1CH SM Fiber Array | Quartz Glass, 127μm Pitch, 8° Angled Polish | Corning SMF-28e, 0.9mm Tube | Low IL <0.3dB, FC/APC
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
1CH SM Fiber Array | Quartz Glass, 127μm Pitch, 8° Angled Polish | Corning SMF-28e, 0.9mm Tube | Low IL <0.3dB, FC/APC
1. Product Overview
This high-precision single-channel single-mode fiber optic array (1CH SMFA) utilizes a premium quartz glass substrate and is specifically designed for high-density optical interconnects and silicon photonics chip coupling.
2. Product Features
| Parameters | Unit | Spec. | Value |
|---|---|---|---|
| Channel | / | 1 | OK |
| Material | / | Quartz Glass | OK |
| Channel Spacing | μm | 127 | OK |
| Polishing Angle | Degree | A8° | OK |
| Package(L)X(W)X(H) | mm | 2.5*2.5*7.9 | OK |
| Insertion Loss | dB | ≤0.3 | |
| Fiber Type | / | SMF-28e | OK |
| Fiber Tube | mm | 0.9 | OK |
| Tube Color | / | White | OK |
| Length | m | 1±0.1 | OK |
| Connector | / | FC/APC | OK |
| Operating Temperature (℃) | 0～65 | OK | |
| Storage Temperature (℃) | -40～85 | OK | |
- Superior optical performance
- Industry-leading wiring
- Ultra-compact quartz packaging
- High-precision end-face processing
- High-reliability terminal protection
3. Applications
- High-Speed Optical Transceiver Packaging
- Silicon Photonics Chip Coupling
- Miniature Optical Passive/Active Devices Integration
- Coherent Optical Communication Systems
- High-Precision Optical Fiber Sensing Systems
