The 32CH DWDM wavelength division multiplexing/demultiplexing module is suitable for 1525–1565nm C-band optical transmission systems, enabling multiplexing and demultiplexing of multi-channel optical signals. The product supports ITU Grid C11–C64 center wavelengths and can also be customized according to customer wavelength plans.
| Parameter | Unit | Value | |||||
|---|---|---|---|---|---|---|---|
| Operating Wavelength | nm | 1525~1565 | |||||
| Special Port | nm | Monitor,1310 (1260~1360) | |||||
| Center Wavelength | nm | ITU Grid(C11 ~C64) or Customized | |||||
| Channel Spacing | nm | 100GHz (0.8nm), 200G(0.8nm) | |||||
| Channel Passband | Min | nm | ±0.11 (100GHz), ±0.25 (200GHz), | ||||
| Channel | - | 32CH | |||||
| Port Insertion Loss | Max | dB | 4.8 | ||||
| Isolation | Adjacent | dB | ≥30 | ||||
| Non-adjacent | dB | ≥40 | |||||
| 1310 Port | Max | dB | 1.0 | ||||
| Ripple | Max | dB | 0.5 | ||||
| PDL | Max | dB | 0.5 | ||||
| Return Loss | Min | dB | 40 | ||||
| Directivity | Min | dB | 50 | ||||
| Power Handing | Max | mW | 300 | ||||
| Fiber Type | - | G67A1/ A2/ B3 or SMF-28 | |||||
| Fiber Coating | um | 250 µm / 900 µm loose tube | |||||
| Fiber Length | mm | 1000 | |||||
| Connector | - | LC/UPC or Customized | |||||
| Dimensions (HxWxD) | mm | 80x58x8, 120x80x18, 155x129x29, 482x250x44 | |||||
| Operating Temperature | °C | -5~65 | |||||
| Storage Temperature | °C | -40~85 | |||||
- 32-channel DWDM architecture, suitable for high-channel-count C-band wavelength multiplexing and demultiplexing.
- Operating wavelength range covers 1525–1565nm.
- Supports a 1310nm Monitor special port, with a port range of 1260–1360nm.
- Center wavelength supports ITU Grid C11–C64, and can also be customized according to customer needs.
- Optional 100GHz / 200GHz channel spacing, channel passband supports ±0.11nm or ±0.25nm.
- Supports customization of various fiber types, connectors, fiber coatings, fiber lengths, and package sizes.
- DWDM optical transmission systems
- Metropolitan area networks, backbone networks, and long-distance fiber optic communication networks
- Multi-wavelength optical signal multiplexing and demultiplexing
- 1310nm Monitor port link monitoring applications
- Optical add-drop multiplexing and wavelength management systems
- Telecommunications Equipment, Optical Transmission Subsystems, and Chassis-Based Equipment Integration
- Fiber Optic Test and Measurement Equipment
We possess complete capabilities in passive optical devices, from optical design and wavelength configuration to precision assembly and packaging manufacturing. For 32CH DWDM modules, we focus on multi-channel filter matching, optical path design, channel consistency, fiber coupling, and packaging structure stability to support reliable integration in high-channel-count systems.
Please contact us for product specifications, sample information, or customized 32CH DWDM solutions. Please provide your channel count, center wavelength, channel spacing, package size, fiber type, connector type, and application requirements. Our engineering team will assist in evaluating and recommending suitable optical design and manufacturing solutions.
