Product Description
14CH PM Fiber Array | 0° Flat Quartz Block, 127μm Pitch | PM II+I Alignment, Slow Axis to Key | High ER 25dB PMFA | Gracyfiber
1. Product Overview
This product is a 14-channel polarization-maintaining fiber array (PMFA), using quartz glass and Corning PM1550 polarization-maintaining fiber. The channel spacing is 127 μm, and the polishing angle is A0°.
2. Core Product Features
| Parameters | Unit | Spec. | Value |
|---|---|---|---|
| Channel | / | 24 | OK |
| Material | / | Quartz Glass | OK |
| Channel Spacing | μm | 127 | OK |
| Polishing Angle | Degree | 0° | OK |
| Package(L)X(W)X(H) | mm | 12*5.7*1.5 | OK |
| Insertion Loss | dB | ≤0.3 | |
| Extinction Ratio | dB | ≥18 | 25 |
| FA PM Fiber Alignment | / | PMII | OK |
| Connctor PM Fiber Alignment | / | Slow Axis Alignment Key |
OK |
| Fiber Type | / | PM1550(Corning) | OK |
| Fiber Tube | mm | 0.9 | OK |
| Tube Color | / | Blue | OK |
| Length | m | 1±0.1 | OK |
| Connector | / | FC/APC | OK |
| Operating Temperature (℃) | 0～65 | OK | |
| Storage Temperature (℃) | -40～85 | OK | |
- 14-channel polarization-maintaining array design
- Low insertion loss performance
- High extinction ratio polarization-maintaining capability
- Precision FA structure design
3. Applications
- 1550 nm polarization-maintaining fiber communication systems
- Coherent optical communication modules
- Multi-channel optical modules and transceiver packaging
- Silicon photonics chip coupling and photonic integration packaging
- Fiber optic sensing, interferometers, and polarization control systems
- Optical path coupling for lasers, modulators, and detectors
- Laboratory optical path testing platforms and high-precision optical equipment
