100GHz 48CH DWDM AAWG Module Flat Top C15 C62 Low Loss Fiber Optic Mux Demux with LC UPC Connector

Name: 100GHz 48CH DWDM AAWG Module Flat Top C15 C62 Low Loss Fiber Optic Mux Demux with LC UPC Connector
Brand: Shenzhen Gracyfiber Technology Co., Ltd.

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: Negotiable

Product Description

100GHz 48CH DWDM AAWG Module Flat Top C15 C62 Low Loss Fiber Optic Mux Demux with LC UPC Connector

1. Product Overview

The flat-top 100GHz DWDM AAWG 48CH module covers C15~C62 channels and is suitable for high-capacity dense wavelength division multiplexing (WDM) systems.

2. Core Product Features

Parameters	Unit	48CH 100G DWDM AAWG Module
Channel	CH	48 (C14~C61)
Chip type	/	Flat Top
Operating wavelength	nm	1525~1565
Channel Spacing	GHz	100
Channel Pass band	nm	ITU±0.11
Insertion Loss	dB	≤5.8
Bandwidth@1dB	nm	≥0.4
Bandwidth@3dB	nm	≥0.6
Adjacent Isolation	dB	≥23
Non-adjacent Isolation	dB	≥29
Non-adjacent Crosstalk	dB	≥21
Return Loss	dB	≥45
Directivity	dB	≥50
Channel Uniformity	dB	≤1.5
Ripple	dB	≤0.5
PDL	dB	≤0.5
Chromatic Dispersion	ps/nm	±20
Operating Temperature	°C	-5~+65
Packaging dimension	mm	L120W70H11

48CH DWDM channels, covering C15~C62
Flat-top AAWG structure, 100GHz channel spacing
Insertion loss IL≤5.5dB
LC/UPC connector interface
0.9mm sleeve length at the branch end (1m), COM end length (1m)
Package dimensions L120×W70×H11mm
Neutral packaging, suitable for system integration and volume delivery

3. Applications

100G DWDM integrated wavelength division systems
Metropolitan area network (MAN) and backbone optical transmission systems
Data center interconnect (DCI)
DWDM multiplexing/demultiplexing modules
Optical transmission equipment and wavelength division multiplexing system integration
High-capacity multi-wavelength optical communication networks
Optical network expansion and wavelength management systems
