4CH O Band LWDM Module LAN WDM Multiplexer Demultiplexer 1295.56 1300.05 1304.58 1309.14nm Low Loss FC UPC
This product is a 4-channel LAN-WDM wavelength division multiplexer, operating at wavelengths of 1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm.
Supports four LAN-WDM wavelengths: 1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm, enabling multiplexed transmission of multiple optical signals.
The single-channel insertion loss IL at room temperature is ≤1.4 dB, helping to reduce link power loss and improve system transmission efficiency.
Utilizes conventional wavelength division multiplexing devices, with a single device transmission loss T ≤0.5 dB and reflection loss R ≤0.3 dB, ensuring stable and reliable overall optical performance of the module.
The module uses a 0.9 mm loose tube with a 1 m fiber outlet length. Internal components have fiber lengths greater than 1.5 m, facilitating module assembly, wiring, and maintenance.
The module is packaged in a 120×80×18 mm ABS plastic box with an FC/UPC connector. Its compact structure and good protection make it suitable for integrated applications in optical communication equipment.
- LAN-WDM Multi-Wavelength Multiplexing Systems
- 100G/400G High-Speed Optical Communication Modules
- High-Speed Optical Interconnects for Data Centers
- Multi-Wavelength Optical Signal Multiplexing and Demultiplexing Systems
- Metropolitan Area Networks, Access Networks, and Short-Distance Optical Transmission Networks
- Integration of Optical Transmission Equipment, Test Platforms, and Passive Wavelength Division Multiplexing Devices
