EC290 Volvo Hydraulic Cylinder Excavator Stick Cylinder 14550433 VOE14550433
Price:
$299-$399
MOQ:
1
Delivery Time:
7 Days
Brand:
Glparts
Product Description
For Volvo EC290 Arm Cylinder Excavator Hydraulic Stick Cylinder 14550433 VOE14550433
|
Product Name |
Excavator Hydraulic Arm Cylinder |
|
Model |
EC290 |
| Part Number |
14550433 VOE14550433 |
|
Cylinder Bore |
70mm-200mm |
| Rod Diameter | 50mm to 150mm |
|
OEM |
Yes |
At Glparts, every hydraulic cylinder is developed and tested in strict accordance with OEM standards, ensuring optimal performance across a wide range of working conditions. Our engineering process integrates advanced heat treatment, precision barrel machining, automated welding, and high-grade surface plating—delivering cylinders that meet the highest benchmarks of quality, strength, and reliability.
Spare Parts of EC290 Hydraulic Cylinder
| Pos | Part No | Qty | Parts name |
| VOE14550433 | [1] | Dipper arm cylinder | |
| VOE14550434 | Dip Arm Cylind | ||
| 1 | VOE14530666 | [1] | Washer |
| 2 | SA1146-02880 | [1] | Pin |
| 3 | VOE14535763 | [1] | Screw |
| 4 | SA9566-40900 | [2] | Back-up ring |
| 5 | SA1146-08130 | [1] | Seal |
| 6 | [1] | Head | |
| 7 | VOE14550724 | [1] | Tube |
| VOE14550888 | Tube | ||
| 8 | VOE14517941 | [1] | Bushing |
| VOE14511731 | Bushing | ||
| 9 | VOE14560205 | [2] | Seal |
| 10 | VOE14550728 | [1] | Rod |
| VOE14550889 | Rod | ||
| 11 | VOE14517941 | [1] | Bushing |
| VOE14511731 | Bushing | ||
| 12 | VOE14560205 | [2] | Seal |
| 13 | SA9567-21050 | [1] | Back-up ring |
| 14 | SA9612-10540 | [1] | Bearing |
| 15 | [1] | Piston | |
| 16 | VOE14510456 | [1] | Seal |
| 17 | SA9565-11500 | [2] | Wear ring |
| 18 | SA9568-01500 | [2] | Seal |
| 19 | SA1146-03190 | [1] | Cushion |
| 20 | SA1146-03170 | [1] | Cushion |
| 21 | VOE13949445 | [15] | Screw |
| 22 | VOE14534347 | [1] | Lock nut |
| 23 | VOE990651 | [2] | O-ring |
| 24 | VOE990594 | [1] | O-ring |
| 25 | SA9556-10500 | [1] | Retaining ring |
| 26 | SA9557-09500 | [1] | Retaining ring |
| 27 | SA9563-21050 | [1] | Seal |
| 28 | SA9564-21050 | [1] | Seal |
| 29 | SA9566-11400 | [1] | Back-up ring |
| 30 | SA9566-31400 | [1] | Back-up ring |
| 100 | VOE14589138 | [1] | Sealing kit |
