Automated Jewelry Fiber Laser Marking Machine Low Maintenance Jewelry Laser Engraving Machine
Jewelry Laser Marking Solutions | Syscode
At Syscode, we specialize in providing cutting-edge laser marking solutions for the jewelry industry, meeting the highest standards of precision and quality. Our advanced systems enable jewelers to engrave intricate designs, logos, and serial numbers on precious metals such as gold, silver, and platinum, ensuring both durability and aesthetic appeal. These laser marking solutions not only enhance the beauty of jewelry but also provide essential traceability and anti-counterfeiting measures for high-value pieces.
Technical Specifications:
| Parameter | FL30 | FL50 | FL100 | ||
| Machine Material | Sandblasted Oxidized Aluminum Structure | ||||
| Laser Source | Fiber Laser Generatorwith aservice life of over 80,000 hours | ||||
| Laser Wavelength | 1064nm | ||||
| MarkingSpeed | ≤12000mm/s | ||||
| Main Control | 10.2-inch Touch Controller | ||||
| Cooling System | Air-cooled at room temperature | ||||
| Focusing Lens | Optional,Focal Length165mm | ||||
| Minimum Line Width | 0.0012mm | ||||
| RepeatPositioning Accuracy | 0.003mm | ||||
| Marking Range | 110mm×110mm(Optional) | ||||
| Positioning Method | Red Light Focusing | ||||
| Number of Marking Rows | Any within themarkingrange | ||||
| Production LineSpeed | 0~130m/min(Dependenton material) | ||||
| Languages | English,French,Spanish,German,Chinese,Russian,Arabic,etc. | ||||
| User Management | Multipleuser management permissions | ||||
| Operating System | Linux | ||||
| Marking Modes | Static,Dynamic,Encoder | ||||
| Reserved Signals | Startprinting,Printing status,Printing complete,Fault alarm | ||||
| Data Protection | Power-off data protection function | ||||
| Missed Mark Detection | Provides overspeed alarm function duetomaterial reflectivity | ||||
| Cross Point Removal | Automatic removal ofcross points to avoid overlapping | ||||
| Printing Software | Supports singleand doublemachine coding | ||||
| Fonts | Standard fonts in Chinese,English,numbers,traditional characters,etc. | ||||
| File Formats | BMP/DXF/HPGL/JPEG/PLT | ||||
| Barcodes | CODE39,CODE128,CODE126,QRCode,Datamatrix(optional) | ||||
| Power Supply | 220V/50HZ | ||||
| Maximum Power Consumption | 400W | ||||
| MachineNet Weight | Split machine:25kg,Integrated machine:17kg:Flying bracket part:22kg | ||||
| Dimensions | Mainbodyof thesplit machine:465X220X332mm Integrated machine:650X195X265mm Opticalpath section of thesplit machine:625X102X110mm | ||||
| Environmental Requirements | Extemaltemperature0℃-45℃;Humidity≤95%;Non-condensing:Novibration | ||||
Why Choose Laser Marking?
Laser marking offers numerous advantages:
- High Precision: Capable of detailed engraving on small surfaces, crucial in the luxury jewelry market.
- Non-contact Process: Reduces the risk of damage as it does not physically touch the jewelry.
- Complex Designs: Allows for intricate patterns and personalized details to be engraved.
- Traceability: Every piece of jewelry can be marked with a unique serial number or logo, ensuring traceability.
Applications of Laser Marking in Jewelry
Laser marking is commonly used for:
- Brand Identification: Ensures each product is recognizable and traceable.
- Serial Numbers for Luxury Goods: Helps combat counterfeit products.
- Custom Engravings: Allows customers to personalize their jewelry with special messages, dates, or initials.
Utilizing laser engraving technology, jewelers can enhance the value of their products. Customization has become a key differentiator in today’s market. This technology is not only efficient but also cost-effective, as it minimizes human error and has low maintenance costs.
Advantages of Syscode Laser Marking Systems
Syscode offers reliable laser marking systems specifically designed for the jewelry industry. Our solutions provide:
- High Precision for Complex Designs.
- Durability: Engravings are permanent and wear-resistant.
- Versatility: Suitable for various materials, including gold, silver, and platinum.
- Cost-effective Solutions: Low maintenance costs, ideal for both small workshops and large production lines.
Our Services
1. Free Pre-Sales Consultation
- Quick Response: We provide pre-sales consultation within 12 hours to address any technical support needs you may have.
- Solution Design: Tailored advanced solutions for all distributors and users.
2. Services During Sales
- Quality Assurance: All machines undergo strict quality control checks and testing before shipment.
- User-Friendly Documentation: Easy-to-understand manuals and operating guides to ensure smooth usage of the equipment.
3. After-Sales Service
- Free Video Training: Comprehensive free video training to help you get started quickly.
- Technical Support: Our technicians provide support via English, video calls, and remote control.
4. Special Design and Customization
- Personalized Service: We are happy to meet your special requirements through innovative design. Whether you need customized machines or OEM orders, please feel free to contact us.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
