300L 600L PP PE PVC Mixing Machine 220V / 380V High Speed PVC Mixer
300/600L Total Capacity PVC PP PE Mixer/mixing Machine Professional and Industrial 220V/380V Voltage
Mixer Machine
1.Widely used in mixing, drying, coloring for all kinds of resin such as PVC, PP, PE, ABS, PC, etc.
2.Composed of one high speed hot mixer and one cooling mixer.
3.The temperature will rise rapidly to meet the requirements of the material mixing process in the hot mixer.
4.The materials from hot mixer will be loaded into the cooling mixer automatically.
5.The materials will be cool down quickly to meet the production process requirement by low-speed mixing blade movement and heat exchange with the water cooling system in the cooling mixer.
| SRL-Z | Heat/Cool | Heat/Cool | Heat/Cool | Heat/Cool | Heat/Cool |
| Total Volume(L) | 100/200 | 200/500 | 300/600 | 500/1000 | 800/1600 |
| Valid Volume(L) | 65/130 | 150/320 | 225/380 | 375/650 | 600/1050 |
| Stirring Speed(Rpm) | 650/1300/200 | 475/950/130 | 475/950/100 | 430/860/60 | 370/740/50 |
| Mixing Time(M) | 8-12 | 8-12 | 8-12 | 8-12 | 8-12 |
| Motor Power(Kw) | 14/22/7.5 | 30/42/11 | 40/55/11 | 55/75/15 | 83/110/22 |
| Output(kg/pot) | 50 | 90 | 120 | 180 | 300 |
