M12 High Speed Metal Tube Laser Cutting Machine With Dual Chuck Design For Automotive Parts Industry
Qiaogongjiang M Series M12 High Speed Metal Tube Laser Cutting Machine features dual chuck design and servo drive system, customized exclusively for automotive parts manufacturing industry. Equipped with full-stroke pneumatic automatic dual chucks, the machine delivers stable clamping and smooth feeding, matched with drawing-free intelligent operating system. It efficiently processes round tubes, square tubes, channel steel, angle iron and other metal profiles ranging from 8–120mm, compatible with stainless steel, iron, aluminum and various metal materials. Balancing high precision, fast cutting speed and ultra-high cost-effectiveness, its short tail piece design greatly reduces material waste. The lightweight body supports easy relocation. Besides automotive spare parts, it is also widely applied in guardrails, storage shelves, stair handrails, bathroom hardware and construction materials processing, serving as the top choice for small & medium factories engaged in mass precision pipe cutting.
-
1. Dual Pneumatic Chuck Design for Automotive Precision Tubes
Upgraded front & rear dual pneumatic automatic chucks with synchronous clamping during operation, eliminating sagging and deviation of long tubes to greatly improve straightness and hole precision. Perfect for mass production of high-precision automotive parts including vehicle frames, exhaust pipes and chassis brackets. Automatic clamping & releasing replaces manual adjustment, doubling loading and unloading speed.
-
2. Upgraded Wide Clamping Range for Full-Size Automotive Profiles
Processing range covers 8–120mm with max clamping diameter up to 120mm. Compatible with round tubes, square tubes, rectangular tubes, channel steel, angle iron and special-shaped profiles widely used in auto manufacturing. One machine handles all sizes of pipes, supporting multi-spec automotive component orders without equipment replacement.
-
3. High-Speed Servo Drive for Max Mass Production Efficiency
Equipped with servo motor drive system, feeding, rotation and cutting actions operate in high-speed linkage. Its cutting speed is over 30% faster than conventional single-chuck models. Optimized programs for standardized mass production of auto parts enable stable non-stop operation and shorter delivery cycles.
-
4. Drawing-Free Intelligent Operating System
Standard drawing-free operating system with built-in template library for automotive pipe cutting. No professional drawing skills required; new operators can quickly master complex processes such as hole punching, bevel cutting and intersecting line cutting for auto parts, cutting enterprise training costs.
-
5. Ultra-Short Tail Piece for High Material Utilization
Tail piece length controlled under 85mm. The dual-chuck structure minimizes leftover scraps when processing long tubes, greatly cutting material waste of thick-walled and special-shaped automotive pipes to lower raw material cost.
-
6. Multi-Material Compatibility for All Auto Metal Raw Materials
Capable of stable cutting on stainless steel, carbon steel, iron and aluminum alloy pipes, covering mainstream metal raw materials of automotive industry. It efficiently processes lightweight aluminum accessories as well as load-bearing carbon steel frame pipes.
-
7. Ultra-High Cost-Effectiveness & Fast ROI for Auto Factories
Economical configuration with stable operation and low failure rate, featuring minimal laser consumable loss. Optimized energy consumption for mass auto parts production, with sufficient output and controllable investment cost to achieve faster return on investment for small & medium auto component factories.
-
8. Lightweight Body for Flexible Production Layout
Lightweight integrated design for easy moving and relocation. It can be fixedly installed in standardized auto parts workshops, or used for supporting outsourced processing and temporary factory production with strong site adaptability.
| Warranty | 12 Months |
| Beam Quality | 1.1m² |
| Acceleration | 2.0G |
| Tolerance | ±0.02mm |
| Application | Metal Pipe Cutting |
| Environment Temperature | 5-35°C |
| Laser Generator | BWT Or RECI Or MAX Or RAYCUS |
| Cutting Accuracy | ±0.02mm |
| Effective Cutting Length | <6000mm |
| Power Supply | 380V, 50Hz, 3-phase |
- Unmatched After-Sales Service: We provide 24/7/365 professional after-sales support, including prompt remote troubleshooting, on-site maintenance, and genuine spare parts supply, ensuring uninterrupted and stable production.
- Original Factory Strength: As a source manufacturer with extensive R&D and production experience, our machines are designed for high efficiency, material-saving performance, and intelligent cutting solutions, minimizing waste and maximizing production benefits.
- Aspirational Spirit & Ultimate Performance: Driven by a commitment to excellence, our machines adopt advanced fiber laser technology, delivering high cutting speed, stable operation, and strong adaptability to meet complex processing requirements.
- Strict Quality Commitment: Comprehensive quality control is applied throughout the entire production process, from raw material selection to final assembly, fully complying with international standards to ensure durable, reliable, and high-precision equipment.
- Intelligent & Efficient Integration: Integrated with intelligent control systems and high-precision cutting technology, the machine enables easy operation without professional drawing skills, significantly improving efficiency and reducing production costs.
![]()
