43 inch Commercial Transparent OLED Touch Screen Standalone Clear OLED
43 Inch Commercial Transparent OLED Touch Screen Display
A Transparent Display Built for Product Storytelling
The 43 inch commercial transparent OLED touch screen display is designed for projects that need more than a standard advertising screen. It allows digital content to appear directly in front of a real product or display scene, while still keeping the background visible. This makes it especially useful for retail windows, brand showrooms, museums, exhibition booths, technology experience centers, and high-end product presentation areas where the physical item must remain visible.
| screen parameters | |||
| Panel size | 43 inches. | Panel type | OLED |
| display area | 941.2 x 529.4 mm | external dimensions | Approx. 953 x 548 x 1.78 mm (W x H x T) |
| transmittance | 43% | viewing angle | 178 °, 178 ° |
| static contrast | 100000:1 (Typ.) Transmission | Dynamic Contrast | 200000:1 (Typ.) Transmission |
| patchwork | Unilateral 5.9mmm, bilateral 12mm, overall unilateral stitching 5.9/5 9/5.9/13 (left/right/top/bottom) | screen scale | 16:9 |
| brightness | 200-600 (nits) | Best resolution | 1920 x 1080 |
| Screen life | ≥ 30000 hours | power | ≤ 190W |
| Display color | 10-Bit, 1.07B (1B = 1 billion) | Speaker | 8Ω/5W * 2 |
| screen gross weight | Screen weight 2.4kg | Gross weight of the whole machine | to be determined |
| environment | Working temperature 1 ℃~ 45 ℃ | working humidity | 30%~80% |
| running time | 18 hours x 7 days | Ambient height | (Altitude) 0~ 5000m |
| response time | 8ms | working voltage | 100V-240VAC, 50/60Hz |
| Fitting method | frame sticker | Fitting method (optional) | Full fit |
| Driver Board | |||
| input interface | HDMI IN | USB | USB 2.0 |
| DP | DP IN | weight | 0.4Kg |
| Control signal IN | RS232 serial port (RJ45) | Control signal OUT | RS232 serial port (RJ45) |
| function | With splicing function | protect | Anti-afterimage, anti-burn, repair function |
| Touch screen parameters: infrared optional | |||
| touch technology | Infrared touch technology | positioning accuracy | 2.5Mm |
| Installation method | Built-in integrated | writing method | Finger ≥ 5mm |
| touch points | 10 touch writing | Writing screen medium | 5-8Mm tempered high-transparency glass, subject to the drawings |
| response speed | ≤ 5ms | computer driven | drive-free |
| mode of communication | USB | service life | ≥ 60 million times |
| Touch screen parameters: capacitance optional | |||
| touch technology | Capacitive touch technology | positioning accuracy | 3Mm |
| Installation method | Built-in integrated | writing method | Finger ≥ 5mm |
| touch points | 10 touch writing | Writing screen medium | 5-8Mm tempered high transparency glass |
| response speed | ≤ 5ms | computer driven | drive-free |
| mode of communication | USB | service life | ≥ 60 million times |
| PC configuration (optional) | |||
| main board | Intel Core | ||
| CPU | 4th generation/6th generation/7th generation/8th generation/10th generation - Core i3/i5/i7 (optional) | ||
| Memory | 4G/8G/16G-DDR3 (optional) | ||
| Hard disk | SSD120G/240G/480-HDD500G/1T/2T (optional) | ||
| nuclear display | Intel HD Graphics 4000 | ||
| Backplane I/O | 1 × DC_IN power interface, 1 × HDMI interface, 1 × VGA interface, 2 × USB3.0 interface, 1 × LAN_RJ interface, 2 × USB2.0 interface, 1 × Mic (input), 1 × PHONE (output) | ||
| Operating System | Win 7/Win 10 operating system | ||
| Android configuration (optional) | |||
| Main board model | 3568/3288/3588 | ||
| Memory | 2G/4G/8G optional | ||
| storage | 16G/32G/64G/128G optional | ||
| interface | 1 × USB2.0, 1 × USB3.0, 1 × DC_IN, 1 × HDMI_OUT, 1 × LAN_RJ, 1 × WIFI, 1 × 3.5 headphone socket, 1 × TFT socket | ||
| Packing and packing list | |||
| Package size | Honeycomb box: approx. 72 x 9 x 112 cm | Air box:/ | |
| Weight information | Bare metal weight: Approx. 38-42 kg | Packing weight (bare metal + honeycomb box): Approx. 48-52 kg | |
| name | With PC/Android | ||
| Specifications | quantity | Remarks | |
| transparent display | 43 inch OLED transparent screen | 1 piece | |
| system | Customized according to actual needs (built-in) | 1 set | |
| remote control | Universal version (without battery) | 1 | |
| Power cord | National standard 1.5 meters | Article 1 | |
| HDMI extension cable Note ② | optional | Article 1 | |
| Touch the USB extension cable Note ② | optional | Article 1 | |
| HDMI signal cable Note ② | optional | Article 1 | |
| Warranty card certificate | Chinese version | 1 sheet | |
| Note: HDMI extension cable, HDMI cable and touch USB extension cable are optional items. The final packing list is subject to the actual shipment of the customer. You can choose whether to configure the extension cable according to customer needs. Note that the selection will incur corresponding costs. Please confirm the price for shipment. | |||
Combine Real Products with Digital Content
With transparent OLED technology, product information, videos, animations, and brand messages can be layered over physical objects. A customer can view the actual item behind the screen while also seeing specifications, feature highlights, usage scenes, or promotional content on the display. Compared with a traditional LCD screen, this creates a more immersive and premium visual effect, helping the product itself remain the focus instead of being hidden behind a monitor.
Create Interactive Experiences Without Blocking the View
The built-in touch function gives visitors a more active way to explore information. Instead of only watching a looping video, users can tap the screen to view product categories, technical details, comparison content, brand stories, or interactive navigation. For stores and showrooms, this can reduce repetitive explanation from sales staff and help customers understand key selling points faster.
What Buyers Should Consider Before Installation
The 43 inch size is practical for medium and small display structures, freestanding showcases, wall-mounted presentation areas, and customized demonstration counters. Before purchasing, buyers should consider the installation environment, ambient light, viewing distance, touch requirements, media playback method, cable routing, ventilation, and whether the display needs to be combined with a cabinet, frame, or custom structure.
This transparent OLED touch display is a strong choice for businesses that want to improve product presentation, increase visitor engagement, and create a cleaner connection between physical items and digital information. It is not only a screen for playing advertisements, but a display solution for building a more interactive and memorable commercial experience.
FAQ
Where can this 43 inch transparent OLED touch screen be used?
It is suitable for retail stores, shopping mall windows, brand showrooms, exhibition booths, museums, experience centers, and product display cabinets.
What is the difference between a transparent OLED display and a normal advertising screen?
A normal advertising screen blocks the view behind it, while a transparent OLED display allows viewers to see both the digital content and the real object behind the screen.
Does the touch function support interactive product presentations?
Yes. The touch function can be used for product menus, feature introductions, brand stories, technical information, and interactive navigation.
What should buyers confirm before placing an order?
Buyers should confirm the installation method, screen location, ambient lighting, viewing distance, content playback requirements, touch usage, and whether a custom frame or display cabinet is needed.
Project note: If you are planning a transparent OLED display project, share your installation space, application scene, and content requirements to receive a suitable commercial display solution.
