86 inch outdoor lcd monitor Board Advertising Display Screen Pantalla De Publicidad Exterior
86 inch outdoor lcd monitor Board Advertising Display Screen Pantalla De Publicidad Exterior
In the outdoor advertising field, an excellent outdoor advertising display can create endless possibilities for brand promotion. The 86-inch outdoor lcd monitor, with its multiple advantages including rainproof, waterproof, lightning protection, and theft prevention, provides a stable platform for displaying advertising information.
Make your brand stand out in high definition; the 86-inch outdoor lcd monitor helps you.
Diverse application scenarios:
Commercial Plazas: The silver-white exterior of the 86-inch outdoor advertising display in a busy commercial plaza will showcase your brand to the fullest, attracting the attention of passersby and enhancing brand influence.
Tourist Attractions: The vertical/horizontal screen design makes the advertising display a focal point at tourist attractions, playing various tourism information to meet tourists' information needs and enhance their travel experience.
Outdoor Events: Setting up a horizontal screen advertising display at outdoor events provides participants with event information and interactive entertainment, enriching the event content.
Powerful Hardware Advantages:
Rainproof and Waterproof Technology: Professional rainproof and waterproof design ensures the advertising display can work normally in rainy weather, providing a stable environment for advertising playback. Lightning protection technology ensures the safety of the equipment and users, and the anti-theft design protects the advertising display from damage.
High-definition LCD screen: The 86-inch LCD screen displays advertising content with excellent picture quality, attracting attention and enhancing advertising effectiveness.
Remote content management: Supports remote content updates, easily enabling information dissemination and keeping advertising content fresh and attractive.
Customizable appearance design: The silver-white exterior is stylish and sophisticated, and custom designs are also available to meet the needs of different brands and better integrate into the environment.
This 86-inch outdoor lcd monitor, both vertical and horizontal, boasts strong protective capabilities and diverse application scenarios, making it a shining star in outdoor advertising. In commercial plazas, tourist attractions, outdoor events, and other settings, it will provide an eye-catching display platform for brand promotion, leading the future of outdoor advertising.
| 85-inch Android Outdoor All-in-One Machine (with Air Conditioning) - Specification Sheet | ||
| Specications | ||
| The containment structure | The material and feature of shell | IP66 waterproof enclosure, 1.5mm zinc coated steel, waterproof and anti-dust design. |
| Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
| LCD Panel | Screen Size | 85 inch |
| Display area | 1860mm(H) X 1046mm(V) | |
| Aspect Ratio | 9:16 | |
| LCD Type | TFT-LCD | |
| Max Resolution | 3840 X 2160 | |
| Display color | 16.7M | |
| Brightness | 2500cd/㎡~3000 cd/㎡ | |
| Contrast Ratio | 4000:1 | |
| Viewing angle(up/down/left/right) | 178°/178°/178°/178° | |
| Response Time | 6ms | |
| Field Frequency | 60Hz | |
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | |
| Touch Overlay for Interactivity | Touch style | Projected Capacitive Touch screen |
| Touch points | 10 points | |
| Ambient light sensor | auto dimming, with light sensor, automatically adjust the brightness. | |
| Drawer-type Android Media Player box Configuration | Processor Chip | RK3399, six core |
| RAM | 4GB | |
| Flash Memory Card | 32GB | |
| Wifi and 4G | Yes | |
| Version | Android 9.0 | |
| Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio format | MP3, WMA | |
| Photo format | BMP, JPEG, PNG, GIF etx | |
| Onboard interface | Network port | RJ45, 10M/100M Adaptive Ethernet |
| HDMI | 1 | |
| USB | 2 | |
| Camera | Built-in 5 Megapixel Camera with 1920X1080 Resolution | |
| Speakers | Dual side speakers for Audio | |
| ECU | Switch power supply | Industrial Power supply |
| Waterproof speaker | High quality waterproof 10W speaker | |
| Thunder Preventer | The tree-level lightning protection | |
| Leakage protective device | Defend Electricity Leakage | |
| Timer | Set up on/off time on day/week/month | |
| Outdoor OMC system(optional) | inlcudes 10 kinds sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor). | |
| Problem and staus monitoring software included. | ||
| Touble shooting by software included. | ||
| Use softwae Remote Check key working performance by Group | ||
| Unnormal work alarm generation | ||
| Built-in Air conditioner for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust internal temperature |
| Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
| Environment | Working temperature | 0℃ ~ 50℃ |
| Working humidity | 5% ~ 95% | |
| Working Voltage | AC 100 ~240v , 50Hz | |
| Max Power Consumption | 500W | |
| Product size / Net weight | To be determined | |
| Outer Package size and Gross weight | ||
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
