32 Inch Self Checkout Machine Supermarket Touch Screen for Shopping Mall and Financial Service
32 Inch Self Checkout Machine Supermarket Touch Screen for Shopping Mall and Financial Service
In contemporary dining and retail settings, customers increasingly prefer "self-selection and quick completion." Long queues and complex manual processes are becoming key obstacles to the customer experience.
A well-designed self-service terminal not only replaces human cashiers but also reshapes the interaction between customers and stores.
This 32-inch upright self-service ordering terminal, with its user-friendly interface layout and integrated payment design, makes the ordering process clear, efficient, and guided, helping stores complete each transaction more smoothly.
| 32-inch floor-standing self-service machine | |||
| LCD Panel Parameters | Screen Size | 32 inch | |
| Display area | 698(H) X 391.8(V)mm | ||
| Aspect Ratio | 16:9 | ||
| LCD Type | a-Si TFT-LCD | ||
| Max Resolution | 1920 X 1080 | ||
| Display color | 16.7M , 72% NTSC | ||
| Brightness | 400 cd/㎡ | ||
| Contrast Ratio | 1200:1 | ||
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
| Response Time | 20ms | ||
| LCD Panel Life(hrs) | 60,000(hrs) | ||
| Field Frequency | 60Hz | ||
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
| Touch points | 10 points | ||
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
| Anti-microbial protection and Shatterproof Protection | |||
| Optically bonded 3mm glass for low parallax | |||
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
| Response speed | < 6ms | ||
| Accuracy of touch | More than 90% of the touch area ±2mm | ||
| Touch ways | Fingers, touch pen | ||
| Output format | The coordinate output | ||
| Clicks time | Unlimited | ||
| The smallest touch size | 5mm | ||
| Long resistance | Yes available | ||
| Touch Interfaces | USB | ||
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Intel Celeron J1900 | |
| RAM | 8GB | ||
| SSD | 64GB | ||
| WIFI | 150Mbps 802.11n wifi integate | ||
| Network port | RJ45, 10M/100M Adaptive Ethernet | ||
| Interface | 2 * RJ45 GB Ethernet | ||
| 2 * RS232 Serial Port | |||
| operating system | Win10 or win11 optional | ||
| Onboard interface | HDMI input | 1 | |
| VGA input | 1 | ||
| DVI input | 1 | ||
| USB Type B or Any USB Type optional | 1 | ||
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
| Receipt Printer | 80mm Thermal printer with cutter | ||
| Power | Power supply | AC 100V~240V, 50/60Hz | |
| The Max power loss | ≤ 45w | ||
| Standby power loss | < 1W | ||
| Features | Operating temperature | 0℃ ~ 50℃ | |
| Storage temperature | below10℃ ~ +60℃ | ||
| Accessories | The length of Power Cable | 1.5m | |
| The length of HDMI Cable | 2m | ||
| The length of USB-A to USB-B Cable | 1.5m | ||
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
| Package size | Machine body size | Customized | |
| Net weight | Customized | ||
| Unit Package size | 570(H) ×550(W) × 1210(D) mm | ||
| The Gross weight of Unit Package | Approx. 30–40 kg | ||
From its product design, it's clear that this device has undergone deep optimization in its user path design.
Firstly, the large, vertical screen structure makes the interface more similar to mobile phone usage logic. From the menu display to the order button, the information hierarchy is clear, allowing users to complete the operation with almost no learning curve. The high-definition display combined with the intuitive UI makes the menu images more attractive, subtly increasing order conversion rates.
Secondly, the integrated functional area at the bottom centrally arranges scanning, payment, and ticketing, shortening the user's operation path. Customers can complete browsing, ordering, and payment in one location, avoiding switching back and forth and improving overall efficiency. This "what you see is what you do" design is ideal for high-frequency, fast-paced scenarios.
Structurally, the upright stand is sturdy and simple, occupying a small area yet highly recognizable, naturally attracting customer attention and forming a self-service ordering entrance. The reinforced base design ensures greater safety and reliability when used in public places.
Furthermore, the device's overall modern and minimalist style blends seamlessly into various store environments, whether it's a chain fast-food restaurant, a milk tea shop, or a shopping mall's dining area, enhancing the space's technological feel and professionalism.
The value of this 32-inch standing self-service ordering terminal lies in simplifying complex service processes into an intuitive user operation path.
It not only reduces human intervention but also allows customers to complete decisions and payments in less time, thereby improving the overall operational efficiency of the store.
For businesses looking to optimize the service experience and enhance their customer service capabilities, this type of equipment has become an indispensable and crucial tool.
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
