APPLICATION
This type of cable is designed for overhead power distribution over long distances, combining high-strength aluminum conductors (AAC, AAAC, or ACSR) with durable XLPE/PVC insulation to ensure reliable performance in aerial installations.
CONSTRUCTION
All aluminium conductor, polyethylene or cross linked polyeth- ylene insulation, concentric strand AAC, ACSR, or 6201 alloy neutral messenger.
CHARACTERISTIC
- Voltage rating: 12.7/22kV
- Normal operation 90°C.
- Emergency over load conditions 130°C.
- Short circuit conditions 250°C.
SPECIFICATION
|
Description |
Phase conductor |
Bare |
Approx.Overall |
||
|
NO of Stranding& |
XLPE |
NO of.Stranding & |
Diameter |
Weight |
|
|
1×10mm²+10mm² |
7 /1.35 |
1.0 |
7/1.35 |
10.30 |
72 |
|
1×16mm²+16mm² |
7/1.70 |
1.2 |
7/1.70 |
12.84 |
113 |
|
1×25mm²+25mm² |
7/2.22 |
1.2 |
7/2.22 |
15.04 |
165 |
|
1×35mm²+35mm² |
7/2.59 |
1.4 |
7/2.59 |
17.8B |
231 |
|
1×50mm²+50mm² |
7/3.10 |
1.4 |
7/3.10 |
19.68 |
318 |
|
1×70mm²+50mm² |
19/2.22 |
1.4 |
19 / 2.22 |
21.38 |
380 |
|
1×95mm²+50mm² |
19/2.59 |
1.4 |
19 / 2.59 |
22.98 |
456 |
|
2×10mm²+10mm² |
7/1.35 |
1.0 |
7 / 1.35 |
12.30 |
116 |
|
2×16mm²+16mm² |
7 /1.70 |
12 |
7 / 1.70 |
15.24 |
181 |
|
2×25mm²+25mm² |
7/2.22 |
12 |
7 / 2.22 |
17.44 |
261 |
|
2×35mm²+35mm² |
7/ 2.59 |
1.4 |
7 / 2.59 |
20.28 |
365 |
|
2×50mm²+50mm² |
7/3.10 |
1.4 |
7 / 3.10 |
22.48 |
498 |
|
2×70mm²+50mm² |
19/2.22 |
1.4 |
19 / 2.22 |
2588 |
622 |
|
2×95mm²+50mm² |
19/2.59 |
1.4 |
19 / 2.59 |
29.08 |
774 |
|
3×10mm²+10mm² |
7/1.35 |
1.0 |
7 / 1.35 |
14.76 |
160 |
|
3×16mm²+16mm² |
7/1.70 |
1.2 |
7 / 1.70 |
18.28 |
249 |
|
3×25mm²+25mm² |
7/2.22 |
1.2 |
7 / 2.22 |
20.92 |
357 |
|
3×35mm²+35mm² |
7/2.59 |
1.4 |
7 / 2.59 |
24.33 |
499 |
|
3×50mm²+50mm² |
7/3.10 |
1.4 |
7 / 3.10 |
26.97 |
678 |
|
3×70mm²+50mm² |
19/2.22 |
1.4 |
19 / 2.22 |
31.05 |
864 |
|
3×95mm²+50mm² |
19/2.59 |
1.4 |
19 / 2.59 |
34.89 |
1092 |
Contact us for more details
ABOUT US
WHY CHOOSE US
PROJECTS
PACKAGE
PARTNER
FAQ
Can ABC cables be used in high-temperature environments?
Yes, XLPE insulation can withstand temperatures up to 90°C under normal conditions and 250°C during short-circuit events, making it suitable for hot climates.
What is the maximum voltage rating for ABC cables with XLPE/PVC insulation?
Typically rated for up to 35 kV, but specific ratings depend on conductor size, insulation thickness, and application requirements.
