APPLICATION
Flame Retardant Armoured Power Cable CU/XLPE/AWA/SWA/PE for Power Transmission is a high-performance cable designed for safe and reliable power transmission in demanding environments
CONSTRUCTION
Conductor:Class 1/Class 2 stranded Copper conductor
Refractory layer:Single sided gold mica tape
Insulation:XLPE
Filler(options):Polypropylene mesh tear rope or flame-retardant filling
Inner Sheath:Polyvinyl chloride (PVC) or flame - retardant polyvinyl chloride
Armoring:Aluminum wire or stainless steel wire (single-core, 73) Galvanized steel wire (multi-core,33)
Outer sheath:Polyethylene (PE)
CHARACTERISTICS
- Voltage Rating Uo/U:0.6/1kV
- Maximum operating temperature of conductor:+90℃
- Operating ambient temperature: -15℃~+55℃
- Cable laying temperature:Not less than 0℃(When the ambient temperature is below 0℃, the cable should be preheated.)
- Minimum Bending Radius: Single core:Single core:15D Multi Core: 12D
SPECIFICATIONS
|
Spec |
Conductor diameter mm |
Approx outer diameter of cable mm |
Approx cable weight kg/km |
|||||||
|
Main wire |
Earth wire |
NH |
ZAN |
ZBN |
ZCN |
NH |
ZAN |
ZBN |
ZCN |
|
|
1×10 |
4 |
/ |
12.6 |
12.6 |
12.6 |
12.6 |
336.4 |
347.4 |
347.4 |
347.4 |
|
1×16 |
5 |
/ |
13.6 |
13.6 |
13.6 |
13.6 |
417.6 |
430.6 |
430.6 |
430.6 |
|
1×25 |
5.59 |
/ |
14.6 |
14.6 |
14.6 |
14.6 |
528.8 |
539.6 |
539.6 |
539.6 |
|
1×35 |
6.62 |
/ |
15.6 |
15.6 |
15.6 |
15.6 |
639.0 |
655.9 |
655.9 |
655.9 |
|
1×50 |
7.65 |
/ |
18.0 |
18.0 |
18.0 |
18.0 |
922.0 |
941.5 |
935.9 |
935.9 |
|
1×70 |
9.21 |
/ |
20.0 |
19.7 |
19.7 |
19.7 |
1176.0 |
1205.1 |
1198.9 |
1198.9 |
|
1×95 |
10.78 |
/ |
21.8 |
21.5 |
21.5 |
21.5 |
1476.0 |
1498.9 |
1491.7 |
1491.7 |
|
1×120 |
12.12 |
/ |
24.2 |
23.9 |
23.9 |
23.9 |
1909.6 |
1930.4 |
1921.9 |
1921.9 |
|
1×150 |
13.69 |
/ |
26.5 |
25.9 |
25.9 |
25.9 |
2262.7 |
2282.0 |
2272.8 |
2272.8 |
|
1×185 |
15.21 |
/ |
28.6 |
28.0 |
28.0 |
28.0 |
2700.3 |
2707.6 |
2697.0 |
2697.0 |
|
1×240 |
17.4 |
/ |
31.2 |
30.6 |
30.6 |
30.6 |
3326.7 |
3355.6 |
3343.4 |
3343.4 |
|
1×300 |
19.55 |
/ |
33.5 |
32.9 |
32.9 |
32.9 |
3974.4 |
4008.2 |
3995.0 |
3995.0 |
|
1×400 |
22.05 |
/ |
37.9 |
37.3 |
37.3 |
37.3 |
5152.5 |
5220.3 |
5203.8 |
5203.8 |
|
1×500 |
25 |
/ |
41.4 |
40.8 |
40.8 |
40.8 |
6354.2 |
6405.4 |
6386.4 |
6386.4 |
|
1×630 |
28.4 |
/ |
45.4 |
44.8 |
44.8 |
44.8 |
7854.1 |
7915.5 |
7893.6 |
7893.6 |
|
2×1.5 |
1.37 |
/ |
13.9 |
14.1 |
14.5 |
14.1 |
314.4 |
344.5 |
357.8 |
344.5 |
|
2×2.5 |
1.75 |
/ |
14.6 |
14.9 |
15.2 |
14.9 |
355.7 |
388.7 |
402.5 |
388.7 |
|
2×4 |
2.22 |
/ |
15.5 |
15.7 |
16.1 |
15.7 |
408.3 |
444.5 |
459.0 |
444.5 |
|
2×6 |
2.74 |
/ |
16.5 |
16.8 |
17.1 |
16.8 |
478.5 |
518.8 |
534.2 |
518.8 |
|
2×10 |
4 |
/ |
20.8 |
21.1 |
21.1 |
21.1 |
812.1 |
882.7 |
882.7 |
874.9 |
|
2×16 |
5 |
/ |
22.8 |
23.1 |
23.1 |
23.1 |
1005.7 |
1076.1 |
1076.1 |
1067.5 |
|
2×25 |
5.59 |
/ |
25.8 |
25.8 |
25.8 |
25.8 |
1414.0 |
1489.7 |
1489.7 |
1480.0 |
|
2×35 |
6.62 |
/ |
27.9 |
27.9 |
27.9 |
27.9 |
1693.3 |
1779.8 |
1779.8 |
1769.3 |
|
2×50 |
7.65 |
/ |
30.3 |
30.3 |
30.3 |
30.3 |
2049.7 |
2261.1 |
2138.6 |
2138.6 |
|
2×70 |
9.21 |
/ |
34.2 |
34.2 |
34.2 |
34.2 |
2647.5 |
2922.2 |
2756.3 |
2756.3 |
|
2×95 |
10.78 |
/ |
38.7 |
38.7 |
38.7 |
38.7 |
3600.9 |
3949.2 |
3739.7 |
3739.7 |
|
2×120 |
12.12 |
/ |
41.9 |
41.9 |
41.9 |
41.9 |
4243.7 |
4660.1 |
4403.5 |
4403.5 |
|
2×150 |
13.69 |
/ |
46.1 |
46.1 |
46.1 |
46.1 |
5040.0 |
5553.3 |
5228.8 |
5228.8 |
|
2×185 |
15.21 |
/ |
51.7 |
51.7 |
51.7 |
51.7 |
6514.4 |
7121.2 |
6748.4 |
6748.4 |
|
2×240 |
17.4 |
/ |
56.8 |
56.8 |
56.8 |
56.8 |
7992.5 |
8739.8 |
8268.6 |
8268.6 |
|
2×300 |
19.55 |
/ |
62.0 |
62.0 |
62.0 |
62.0 |
9560.4 |
10476.5 |
9898.4 |
9898.4 |
|
2×400 |
22.05 |
/ |
68.4 |
68.4 |
68.4 |
68.4 |
11611.0 |
12736.1 |
12009.9 |
12009.9 |
|
3×1.5 |
1.37 |
/ |
14.4 |
14.7 |
15.0 |
14.7 |
347.3 |
378.4 |
391.8 |
378.4 |
|
3×2.5 |
1.75 |
/ |
15.2 |
15.5 |
15.8 |
15.5 |
398.4 |
432.3 |
446.4 |
432.3 |
|
3×4 |
2.22 |
/ |
16.2 |
16.4 |
16.8 |
16.4 |
469.7 |
506.9 |
521.6 |
506.9 |
|
3×6 |
2.74 |
/ |
17.3 |
17.5 |
17.9 |
17.5 |
559.9 |
601.2 |
616.7 |
601.2 |
|
3×10 |
4 |
/ |
21.8 |
22.1 |
22.1 |
22.1 |
945.2 |
1017.1 |
1017.1 |
1008.9 |
|
3×16 |
5 |
/ |
24.0 |
24.3 |
24.3 |
24.3 |
1205.0 |
1276.6 |
1276.6 |
1267.5 |
|
3×25 |
5.59 |
/ |
27.2 |
27.2 |
27.2 |
27.2 |
1718.6 |
1795.0 |
1795.0 |
1784.8 |
|
3×35 |
6.62 |
/ |
29.4 |
29.4 |
29.4 |
29.4 |
2086.7 |
2173.8 |
2173.8 |
2162.7 |
