XLPO/LSZH Solar PV Cable 2.5mm2 4mm2 6mm2 10mm 16mm for Solar Panel System
XLPO/LSZH Solar PV Cable 2.5mm2 4mm2 6mm2 10mm 16mm for Solar Panel System
APPLICATION
The cables are commonly used in solar photovoltaic (PV) systems because of their excellent properties, such as high durability, low fire risk, and environmental safety.
CONSTRUCTION
- Conductor: Class 5 tinned copper conductors
- Insulation: Halogen free flame-retardant insulation material for solar cables
- Outer sheath:Halogen free flame retardant sheath material for solar cables
CHARACTERISTIC
- Voltage Rating: Uo/U:1.0/1.0kV Um:1.5kV
- Maximum operating temperature of conductor:+120℃
- Operating ambient temperature: -40℃~+90℃
- Cable laying temperature:Not less than -25℃
- Minimum Bending Radius: 6D
SPECIFICATIONS
|
Cross section(mm²) |
Conductor Construction(no/mm) |
Conductor Stranded OD.max(mm) |
Cable OD.(mm) |
Approximate weight of cable |
Max Conductor Resistance(Ω/km,20°C) |
|
1×1.5 |
48/0.20 |
1.58 |
4.8 |
35 |
13.7 |
|
1×2.5 |
77/0.20 |
2.02 |
5.2 |
47 |
8.21 |
|
1×4 |
56/0.285 |
2.46 |
5.7 |
64 |
5.09 |
|
1×6 |
84/0.285 |
3.01 |
6.3 |
86 |
3.39 |
|
1×10 |
77/0.40 |
4.1 |
7.2 |
128 |
1.95 |
|
1×16 |
7×17/0.40 |
5.5 |
8.9 |
196 |
1.24 |
|
1×25 |
7×27/0.40 |
6.7 |
10.7 |
299 |
0.795 |
|
1×35 |
7×38/0.40 |
8.2 |
12.4 |
407 |
0.565 |
|
1×50 |
19×20/0.40 |
10.0 |
14.6 |
571 |
0.393 |
|
1×70 |
19×28/0.40 |
11.6 |
16.4 |
773 |
0.277 |
|
1×95 |
19×38/0.40 |
13.5 |
18.5 |
1024 |
0.210 |
|
1×120 |
24×38/0.40 |
14.4 |
19.8 |
1266 |
0.164 |
|
1×150 |
30×38/0.40 |
16.2 |
22.2 |
1584 |
0.132 |
|
1×185 |
37×38/0.40 |
18.2 |
25.0 |
1967 |
0.108 |
|
1×240 |
48×38/0.40 |
20.6 |
27.8 |
2518 |
0.0817 |
