MV AWA Armoured Electrical Cable 3.6/6kV～26/35kV AL/XLPE/AWA/ SWA/LSZH Customized Length

Name: MV AWA Armoured Electrical Cable 3.6/6kVuff5e26/35kV AL/XLPE/AWA/ SWA/LSZH Customized Length
Brand: Zhongdong Cable Co., Ltd.

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: 7-30 days based on different qty

Brand: Low Smoke Zero Halogen Cable

Product Description

MV AWA Armoured Electrical Cable 3.6/6kV～26/35kV AL/XLPE/AWA/ SWA/LSZH Customized Length

APPLICATION

Widely used in industrial power grids, energy infrastructure, underground substations, and cross-border power engineering projects

CONSTRUCTION

Conductor : Aluminium

Insulation :XLPE

Filler :LSZH

Armour :Single core: AWA (Aluminium wire armour) All other sizes: SWA (Galvanized round steel wire)

Sheath :LSZH

STANDARD

EN 60502-2

CHARACTERISTICS

Voltage Rating Uo/U:3.8/6.6(7.2)kV, 6.35/11kV(12)kV, 8.7/15(17.5)kV, 12.7/22 (24)kV, 19/33(36)kV

Maximum operating temperature of conductor:+90℃

Operating ambient temperature: -15℃~+55℃

Cable laying temperature:Not less than 0℃(When the ambient temperature is below 0℃, the cable should be preheated.)

SPECIFICATION

26/35kV

Specs mm²	Conductor diameter mm	Outer thickness of insulation ±1.0mm	Approx outer diameter of cable mm	Approx cable weight kg/km	Specs mm²	Conductor diameter mm	Outer thickness of insulation ±1.0mm	Approx outer diameter of cable mm	Approx cable weight kg/km
1×50	7.6±0.2	31.2	41.2	2192	3×50	7.6±0.2	31.2	833	7350
1×70	9.2±0.2	32.8	43.0	2376	3×70	9.2±0.2	32.8	86.9	7989
1×95	10.9±0.2	34.5	44.7	2554	3×95	10.9±0.2	34.5	903	8633
1×120	12.2±0.2	35.8	46.1	2738	3×120	12.2±0.2	35.8	93.6	9314
1×150	13.6±0.2	37.2	47.7	2939	3×150	13.6±0.2	37.2	96.8	10003
1×185	15.2±0.2	38.8	49.5	3182	3×185	15.2±0.2	38.8	100.6	10803
1×240	17.4±0.2	41.0	51.7	3493	3×240	17.4±0.2	41.0	105.8	11996
1×300	19.5±0.2	43.1	54.1	3855	3×300	19.5±0.2	43.1	110.4	13154
1×400	22.0±0.2	45.6	56.8	4349	3×400	22.0±0.2	45.6	117.8	14927
1×500/35	24.8±0.2	49.2	63.1	5275	3×500/35	24.8±0.2	49.2	129.7	18186
1×630/35	28.2±0.2	52.6	66.9	5949	3×630/35	28.2±0.2	52.6	137.8	20526
1×800/35	34.0±0.2	58.4	72.8	6872

FAQ

Q: Can you provide customized cable solutions?
A: Yes. We offer OEM/ODM services for custom conductor cross-sections (from 1.5mm² to 1000mm²), voltage ratings (low/medium/high voltage), armouring types (SWA/AWA/galvanized steel) and sheath materials (PVC/LSZH/XLPE).
Q: What is the lead time for cable orders?
A: For standard cables, the lead time is 7–30 working days for bulk orders. Customized cables require 20–30 working days, depending on the complexity of specifications and order volume.
Q: How do you ensure product quality during production?
A: We implement strict quality control (QC) at every stage: raw material inspection, online production testing, and final electrical/mechanical performance checks (e.g., voltage withstand, insulation resistance, tensile strength tests). All products pass 100% inspection before shipment.
Q: Do you provide free samples?
A: We offer free samples for quality testing. The customer only needs to cover the shipping cost.
Q: Can you provide technical support for cable installation?
A: Yes. We provide detailed installation manuals, and our technical team is available 24/7 to offer guidance on cable routing, armouring handling, and joint termination. On-site support can be arranged for large-scale projects.
Q: What is your warranty policy for cables?
A: We provide a 12–24 month warranty for all our cables, depending on the product type. During the warranty period, we will replace or repair any defective products caused by manufacturing issues free of charge.
Q: What is the minimum order quantity (MOQ) for cables?
A: We have a flexible MOQ requirement. For customized cables, the MOQ is determined by the specific specifications, and we can accommodate small trial orders for new customers.
Q: How do you package and ship the cables?
A: Cables are wound on sturdy wooden or steel reels, wrapped with waterproof plastic film to prevent moisture damage. We ship via sea freight (FCL/LCL) for bulk orders and air freight for urgent small orders, with full tracking provided.
