Aluminium Foil Screened Control Cable Fire Rated IEC 60227 Standard Cable
Aluminium Foil Screened Control Cable Fire Rated IEC 60227 Standard Cable
APPLICATION
Aluminium foil screened fire rated control cable compliant with IEC 60227 is designed for reliable signal and control transmission in fire-critical environments. It offers excellent EMI protection and maintains circuit integrity under fire conditions, making it ideal for fire alarm systems, industrial control, and public infrastructure projects.
Key Selling Points
- Fire Resistant Performance
Maintains circuit integrity under fire conditions (in accordance with IEC 60331) - EMI Shielding
Aluminium foil screen ensures stable signal transmission with minimal interference - Reliable in Critical Applications
Suitable for fire alarm, emergency systems, and safety circuits - IEC Standard Compliance
Manufactured according to IEC 60227 with flame retardant properties per IEC 60332 - Flexible and Easy Installation
PVC insulated design suitable for indoor, conduit, and cable tray installations - Wide Application Range
Ideal for power plants, substations, industrial automation, and infrastructure projects
CONSTRUCTION
- Conductor:Circular solid copper conductor(A) or circular stranded copper conductor(B)
- Insulation:Polyvinyl chloride (PVC)
- Filler:Polypropylene(PP) mesh filling rope
- Screen:Aluminum foil or copper wire
- Outer sheath:Polyvinyl chloride (PVC)
CHARACTERISTIC
- Voltage Rating Uo/U: 450/750V
- Temperature Rating
- Maximum operating temperature of conductor:+70℃
- Operating ambient temperature: -15℃~+45℃
- Cable laying temperature:Not less than 0℃(When the ambient temperature is below 0℃, the cable should be preheated.)
- Minimum Bending Radius: 6D (D is the actual outer diameter of the cable)
SPECIFICATION
|
Spec mm² |
Conductor No core/mm |
Conductor diameter mm |
Approximate outer diameter of cable |
Approximate cable weight |
|||||||||
|
None |
ZA |
ZB |
ZC |
None |
ZA |
ZB |
ZC |
||||||
|
4×1 |
1/1.13 |
1.13 |
8.8 |
9.1 |
9.1 |
8.8 |
102.4 |
111.5 |
111.5 |
102.4 |
|||
|
7×1 |
1/1.13 |
1.13 |
10.3 |
10.6 |
10.6 |
10.3 |
153.2 |
158.8 |
158.8 |
153.2 |
|||
|
10×1 |
1/1.13 |
1.13 |
12.8 |
13.1 |
13.1 |
12.8 |
220.0 |
230.6 |
230.6 |
220.0 |
|||
|
14×1 |
1/1.13 |
1.13 |
14.4 |
14.7 |
14.7 |
14.4 |
299.7 |
311.4 |
311.4 |
299.7 |
|||
|
19×1 |
1/1.13 |
1.13 |
15.9 |
16.2 |
16.2 |
15.9 |
371.7 |
380.9 |
380.9 |
371.7 |
|||
|
27×1 |
1/1.13 |
1.13 |
18.9 |
19.1 |
19.1 |
18.9 |
522.6 |
540.0 |
540.0 |
522.6 |
|||
|
37×1 |
1/1.13 |
1.13 |
21.4 |
21.7 |
21.7 |
21.4 |
679.0 |
691.8 |
691.8 |
679.0 |
|||
Contact us for more details
FAQ
What types of cable products does your company primarily manufacture?
We specialize in the production of various types of power cables, control cables, communication cables, and specialty cables, including but not limited to PVC-insulated cables, XLPE power cables, mining cables, marine cables, and photovoltaic cables.
Which international standards do your products comply with?
Our products comply with various international standards, such as IEC, BS, UL, ASTM, GB, etc., depending on the product type. We can provide products compliant with different international standards.
What quality certifications do you hold?
We have obtained ISO and CCC quality management system certifications, and some products have also obtained international certifications. We can also apply for specific certifications based on customer requirements.
What is the delivery lead time?
Standard products are typically in stock and can be shipped within 7-15 days. Customized products require 15-45 days depending on quantity.
Do you accept customized products?
We provide OEM and ODM service, we can customize cable products according to customer's special requirements, including specifications, colors, packaging and so on.
