Alkaline D LR20 1.5 Volt Battery LR20 Primary Battery Alkaline D Size Batteries
Alkaline D size Battery LR20 D/LR20 1.5V Alkaline Battery Lr20 Battery 1.5V D Alkaline LR20 Battery
High Performance D Non-Rechargeable Batteries for Clocks, Remotes, Toys & Electronic Devices, Replacement D Cell Batteries
LR20 is the IEC name for alkaline D cell battery. This is a NON-Rechargeable Battery 1.5V
Long Lasting D/ LR20 Cell Long Life Alkaline batteries.
Designed for to provide reliability and lasting performance for high and low drain products
1.5V Alkaline D batteries lr 20 D Batteries are a standard size of dry cell battery that are used for higher drain power applications.
They are often referred to as 'Flashlight Batteries', due to their use in large torches which require long lasting power and performance.
D Cell batteries are still commonly used in many larger appliances, such as portable radios and electronic toys.
LR20 batteries D cell cylindrical Alkaline D batteries specificate:
Type: Disposable battery
Part number: LR20
Battery size : D
Chemical System: Zn/KOH—H2O/MnO2
Nominal voltage: 1.5V
Average weight: 135g
Jacket: Foil Label
Reference document: IEC60086-2: 2021,
IEC60086-1: 2021, GB/T8897.1.2-2021, GB/T8897.5-2019
Heavy Metal Contents:
|
Hg |
Cd |
Pb |
|
<1 ppm |
<10 ppm |
<10 ppm |
Alkaline batteries D Size AlkaLine Battery Advantage:
Long-lasting and stable power output
0% Mercury, eco-friendly, reducing potential pollution
High-density structure, providing ultra-high performance and long-lasting power
Suitable for medium to high power-consuming electronic devices
Up to 5 year Shelf Life
QUALITY ASSURANCE for D battery 1.5volt dry cell battery D
High-density Zinc manganese battery 1.5Volt D dry cell battery Data sheet for LR20 D size battery
| Model | LR20 D Household dry cell battery |
| Diameter | 32.3-34.2 |
| Height | 59.5-61.5 |
| Norminal voltage |
1.5 volt |
| Test condition/discharge time | 22Ω, 24h/d, 0.8V / 19 H |
| 3.9Ω, 1h/d, 0.9V / 40H | |
| Storage time | more than 5 years |
| LOGO | OEM |
| Package | Welcome OEM customer logo too |
| Battery pack | any combinations welcome customized |
Hot sale Alkaline batteries from Hynna Alkaline Intense D industrial batteries factory
Alkaline Primary cell 1.5 volt battery Mercury-Free Battery D size battery 1.5v
| Model | Diameter mm | Height mm | Norminal Voltage V | Test condition | Discharge |
| 23A | 9.9-10.2 | 28.1-28.7 | 1.5 | 20KΩ, 24h/d, 7.2V | 98h |
| 27A | 7.65-7.85 | 27.7-28.3 | 1.5 | 20KΩ, 24h/d, 7.2V | 36h |
| LR03/AAA/七号 | 9.5-10.5 | 43.3-44.5 | 1.5 | 10Ω, 24h/d, 0.9V | 8h |
| 3.9Ω, 24h/d, 0.9V | 2.5h | ||||
| LR6/AA/五号 | 13.5-14.5 | 49.2-50.5 | 1.5 | 10Ω, 24h/d, 0.9V | 19.1h |
| 3.9Ω, 24h/d, 0.9V | 6.4h | ||||
| LR14/C/二号 | 24.9-26.2 | 48.6-50.0 | 1.5 | 3.9Ω, 24h/d, 0.8V | 20h |
| 6.8Ω, 1h/d, 0.9V | 39h | ||||
| LR20/D/大号 | 32.3-34.2 | 59.5-61.5 | 1.5 | 22Ω, 24h/d, 0.8V | 19h |
| 3.9Ω, 1h/d, 0.9V | 42h | ||||
| 6LR61/9V | 26.5*17.5*48.5 | 9 | 180Ω, 24h/d, 4.8V | 800min | |
| 270Ω, 1h/d, 5.4V | 1150min | ||||
Rechargeable battery 1.5volt Alkaline cell Plus D 1.5V Alkaline Batteries
| Model | Diameter | Height | Norminal Voltage | Test condition | Discharge | Cycle life Times |
| HR03/AAA/7号 | 9.5-10.5 | 43.3-44.5 | 1.5 | 100mA, 24h/d, 0.9V | 900mAh | 50-200 times |
| 300mA, 24h/d, 0.9V | 600mAh | 50-200 times | ||||
| HR6/AA/5号 | 13.5-14.5 | 49.2-50.5 | 1.5 | 100mA, 24h/d, 0.9V | 1800mAh | 50-200 times |
| 300mA, 24h/d, 0.9V | 1500mAh | 50-200 times |
