9 Volt 6lr61 Pp3 Alkaline 9V Battery Dry Cell Long-lasting Support OEM And ODM Service
9 volt 6lr61 battery 9V pp3 alkaline battery 9V dry cell battery
Alkaline Battery 9V 6LR61T/1BK Alkaline Battery 9Volt MAX 9V Alkaline Batteries 6LR61 9 Volt Alkaline Batteries
These alkaline 9V batteries provide long lasting power for your everyday devices
9V dry cell battery with long-lasting power into everyday life.
9v 6f22 alkaline battery alkaline 6lr61 9v batteries 6f22 9 volt battery alkaline 9v batteries 9v alkaline iec 6lr61 mn1604 9v battery
9V battery 6LR61 alkaline battery Technical Specifications:
Voltage: 9V (Nominal)
Chemistry: Alkaline (Zinc-Manganese Dioxide)
Capacity: ~550-600 mAh (depending on brand and load)
Operating Temperature: Typically -20°C to 54°C (-4°F to 130°F)
Terminal Type: Snap-on (male/female clasp terminals)
Common Standards: IEC 6LR61, ANSI 1604A
| Model | 6LR61, 9V, 6lr6 |
| Dimensions | 26.5*17.5*48.5 mm |
| Weight | 45g |
| Norminal voltage |
9 volt |
| Test condition/discharge time | 180Ω, 24h/d, 4.8V / 800min |
| 270Ω, 1h/d, 5.4V / 1150min | |
| Storage time | more than 5 years |
| LOGO | OEM |
| Package | Welcome OEM customer logo too |
| Battery pack | any combinations welcome customized |
Alkaline batteries 9V primary battery Attentions:
1) Batteries should be placed in a cool place before use
2) Please install the battery according to the positive and negative (+/-) polarity instructions of the electronic product.
3) Never mix different brands, different types or old and new batteries
4) Never charge, disassemble, damage or dispose of battery in fire
5) Never connect the positive and negative (+/-) terminals of the same battery
6) Never put unpackaged batteries in your pocket
7) If you do not use electronic products for a long time, please remove the batteries
8) Never swallow batteries
9) Batteries are not toys, please do not let children touch or use them
9V size dry cell battery LR61 battery 9 volt
| Type | Diameter mm | Height mm | Weight kg |
Capacity mah |
Testing condition |
| 6LR61/ 9V | L 24.5~26.5 W15.5~17.5 |
46.5~48.5 | 0.0435 | 500 | 35mA, 24h/d, 20°c,e.v.=5.4V |
We are welcome any OEM and ODM service for all the alkaline batteries LR61 battery 9volt battery
| Blister packing | Shrink packing | ||||||||
| Pack | Inner box | Carton | Measurement | G/W | Pack | Inner box | Carton | Measurement | G/W |
| 1B/card | 30 cards | 240cards | 391*299*237mm | 13.9 kgs | 1S/shrink | 20 pcs | 360 pcs | 291*237*179 mm | 16.9 kgs |
9v battery for home applications dry cell battery lr61
Primary cell 1.5 volt batteries
| Model | Diameter mm | Height mm | Norminal Voltage V | Test condition | Discharge |
| 23A | 9.9-10.2 | 28.1-28.7 | 1.5 | 20KΩ, 24h/d, 7.2V | 98h |
| 27A | 7.65-7.85 | 27.7-28.3 | 1.5 | 20KΩ, 24h/d, 7.2V | 36h |
| LR03/AAA/七号 | 9.5-10.5 | 43.3-44.5 | 1.5 | 10Ω, 24h/d, 0.9V | 8h |
| 3.9Ω, 24h/d, 0.9V | 2.5h | ||||
| LR6/AA/五号 | 13.5-14.5 | 49.2-50.5 | 1.5 | 10Ω, 24h/d, 0.9V | 19.1h |
| 3.9Ω, 24h/d, 0.9V | 6.4h | ||||
| LR14/C/二号 | 24.9-26.2 | 48.6-50.0 | 1.5 | 3.9Ω, 24h/d, 0.8V | 20h |
| 6.8Ω, 1h/d, 0.9V | 39h | ||||
| LR20/D/大号 | 32.3-34.2 | 59.5-61.5 | 1.5 | 22Ω, 24h/d, 0.8V | 19h |
| 3.9Ω, 1h/d, 0.9V | 42h | ||||
| 6LR61/9V | 26.5*17.5*48.5 | 9 | 180Ω, 24h/d, 4.8V | 800min | |
| 270Ω, 1h/d, 5.4V | 1150min | ||||
Rechargeable Alkaline battery 1.5 volt
| Model | Diameter | Height | Norminal Voltage | Test condition | Discharge | Cycle life Times |
| HR03/AAA/7号 | 9.5-10.5 | 43.3-44.5 | 1.5 | 100mA, 24h/d, 0.9V | 900mAh | 50-200 times |
| 300mA, 24h/d, 0.9V | 600mAh | 50-200 times | ||||
| HR6/AA/5号 | 13.5-14.5 | 49.2-50.5 | 1.5 | 100mA, 24h/d, 0.9V | 1800mAh | 50-200 times |
| 300mA, 24h/d, 0.9V | 1500mAh | 50-200 times |
STORAGE
(1) Store in cool, dry place before use.
(2) Do not keep batteries at temperature of 55℃ or above.
(3) Do not keep batteries at relative humidity of 85% or above.
