All In One Hybrid Solar Inverter 5kw High Efficiency 220vac 230vac MPPT Parallel 48volt
Price:
CN¥1,747.07/pieces 1-99 pieces
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
SZSSTH
Product Description
All In One 5kw 5000w High Efficiency 220vac 230vac MPPT Parallel Inverter 48volt Hybrid Solar Inverter Converters
Products Description
Product Features
Product Features
1. Pure sine wave solarinverter
1. Pure sine wave solarinverter
2. Built-in40AMPPT solar charger
3. PVinput voltage range 20~150VDC (for 1000W),30~150VDC(for 1500W)
4. Built-in anti-dust kit for harsh environment
5. Smart battery charge design to optimize battery lifemeet rich customizeddemands
6. Solar energy is provided directly to the load first
|
|
SUF3000S4A1
|
SUF5000S4A1
|
||
|
BatteyInput
|
|
|
||
|
Battery Type
|
Li-lon/Lead-acid
|
Li-lon/Lead-acid
|
||
|
BatteryVoltage
|
24Vdc
|
48Vdc
|
||
|
Inverter Output
|
|
|
||
|
Nominal Power(W)
|
3000
|
5000
|
||
|
Nominal Apparent Power (VA)
|
3000
|
5000
|
||
|
Paralll Capacity
|
No
|
Yes.9 units maximum
|
||
|
AC Voltage Regulation (Battery Mode)
|
230Vac±5%@50/60Hz
|
230Vac±5%@50/60Hz
|
||
|
Surge Power (VA)
|
6000
|
10000
|
||
|
Eficiency (peak)
|
93%
|
93%
|
||
|
Waveform
|
Pure sine wave
|
Pure sine wave
|
||
|
Transfer Time
|
10ms (for personal computers), 15ms (for home appliances)
|
|
||
|
SolerCharge
|
|
|
||
|
Max.PV Array Power (W)
|
4000
|
6000
|
||
|
|
|
|
||
|
MPPT Range @OperatingVoltage
|
120Vdc-430Vdc
|
120Vdc-430Vdc
|
||
|
Number of Independent MPP Trackers
|
1
|
1
|
||
|
Number of Strings Per MPPT
|
1
|
1
|
||
|
Max,Input Current Per MPPT(A)
|
16
|
18
|
||
|
Max.PV Array Open Circuit Voltage (V)
|
500Vdc
|
500Vd
|
||
|
Max Solar Charge Current (A)
|
120
|
80
|
||
|
Ac Charger
|
|
|
||
|
Max.AC Charge Current(A)
|
120
|
80
|
||
|
AC Input Voltage (V)
|
230Vac
|
230Vac
|
||
|
Voltage Range (V)
|
170-280Vac (For PersonalComputers); 90-280 Vac(For Home Appliances)
|
|
||
|
Frequency Range(Hz)
|
50/60
|
50/60
|
||
|
General
|
|
|
||
|
UserInterface
|
APP+LCD Display+LED
|
|
||
|
Communication
|
USB,Optional:Wi-Fi,4G,GPRS,RS485/CAN,Dry-contact
|
|
||
|
Ingress Protection Rating
|
IP54
|
IP54
|
||
|
Dimension (W*H*D mm)
|
300*450*110.5
|
300*450*110.5
|
||
|
Weight (kg)
|
7.5 8
|
|
||
|
Relative Humidity
|
20%~95%
|
20%~95%
|
||
|
Max.Operating Altitude (m)
|
2000m, >1000m derating
|
2000m,>1000m derating
|
||
|
Operating Temperature (°C)
|
0~50
|
0~50
|
||
|
Storage Temperature (°C)
|
[-15~60]
|
[-15~60]
|
||
|
Protection
|
|
|
||
|
PV Over VoltageProtection
|
Yes
|
|
||
|
PV Over Current Protection
|
Yes
|
|
||
|
Battery Over Voltage Protection
|
Yes
|
|
||
|
Battery Over Current Protection
|
Yes
|
|
||
|
AC Surge Protection
|
Type II
|
|
||
|
Output OverCurrentProtection
|
Yes
|
|
||
|
Output Short Circuit Protection
|
Yes
|
|
||
|
Output OverVoltage Protection
|
Yes
|
|
||
