22.8V 16000mAh Lipo Drone Battery 100A Peak Discharge 300 Cycles
OiDA175175-16000-15C-22.8 Drone Battery 22.8V 16000mAh 100A Peak Discharge 300 Cycles
Product Name
High-Performance 6S1P 22.8V 16000mAh Lithium Polymer Drone Battery
Advantages
- Optimized for high-power drone applications with 15C discharge capability.
- Lightweight design (1780g) for improved flight efficiency.
- Extended cycle life for long-term reliability.
Specifications
|
No. |
Item |
Specification |
|
1 |
Configuration |
6S1P (6 Series, 1 Parallel) |
|
2 |
Nominal Voltage |
22.8V (Cell: 3.8V) |
|
3 |
Nominal Capacity |
16000mAh @ 0.2C Discharge |
|
4 |
Minimum Capacity |
15582mAh @ 0.2C Discharge |
|
5 |
Open-Circuit Voltage |
25.8V–26.1V (Cell: 4.30V–4.35V) |
|
6 |
Max Charge Current |
10A (0.4C) to 26.1V, CV until ≤0.02C |
|
7 |
Max Continuous Discharge |
50A (3.1C) to 19.2V |
|
8 |
Peak Discharge Current |
100A (6.2C, ≤3s) |
|
9 |
Internal Impedance |
≤9mΩ |
|
10 |
Dimensions (T×W×H) |
64×77.5×196mm (Max) |
|
11 |
Weight |
1780g (Approx.) |
|
12 |
Terminals |
XT90-S (Discharge), JST-XHR-7P (Balance) |
Cycle Life
|
Test Condition |
Performance |
|
1. Charge: 5A to 26.1V, end current ≤0.02C |
|
|
2. Rest: 10min |
|
|
3. Discharge: 5A to 19.2V |
≥300 cycles (80% capacity retention) |
|
4. Rest: 30min |
|
|
5. Repeat steps 1–4 until capacity <80% |
Discharge Curve
- 100A Discharge: ≥5.4 minutes to 19.2V after standard charge.
- Low-Temp Performance: ≥75.1% capacity at -20°C (0.2C discharge).
Operating Temperature Range
|
Scenario |
Temperature Range |
|
Charging |
10°C to 45°C |
|
Discharging |
-20°C to 60°C |
|
Storage (Short-term) |
-20°C to 35°C (≤7 days at >23.4V) |
|
Storage (Long-term) |
-20°C to 35°C (21.6V–23.4V, activate every 3 months) |
Certifications
- Complies with RoHS and UN38.3 safety standards.
Key Features
- Ultra-Fast Charging: Fully charges in 1.5 hours (10A) or 3 hours (5A).
- High-Temp Stability: 95% capacity recovery after 60°C storage.
- Low Self-Discharge: ≤15% capacity loss after 28 days at 23°C.
Applications
- Heavy-lift drones, industrial UAVs, and high-endurance aerial photography.
![]()
Usage Warnings & Precautions
- Charging: Use CC/CV chargers (max 26.1V). Reverse polarity prohibited.
- Discharging: Avoid >100A currents or temperatures <-20°C/＞60°C.
- Physical Handling: Protect aluminum casing from sharp objects.
Storage Guidelines
- Short-term: Store at 22.5V–23.1V (20°C).
- Long-term: Maintain 21.6V–23.4V; activate every 3 months (0.2C cycle).
Warranty & Disclaimer
- Warranty void if modified or misused (overcharge, puncture, etc.).
- Not liable for accidents caused by improper operation.
