22.8V 16000mAh Drone Battery with 100A Peak Discharge
OiDA375175-16000-15C-22.2 Drone Battery 22.2V 16000mAh 100A Peak Discharge 150 Cycles
Product Name
OiDA375175-16000-15C-22.2 Drone Battery
Advantages
- High energy density for extended flight time
- Stable performance under extreme temperatures
- Robust cycle life for long-term use
Specifications
|
Parameter |
Value |
|
Nominal Voltage |
22.2V (6S1P) |
|
Nominal Capacity |
16000mAh (0.2C discharge) |
|
Minimum Capacity |
15000mAh |
|
AC Impedance |
≤11mΩ (1kHz AC method) |
|
Charging |
|
|
Standard Charge Current |
0.2C (3200mA) |
|
Fast Charge Current |
0.5C (8000mA) |
|
Max Charge Voltage |
25.2V |
|
Discharging |
|
|
Standard Discharge Current |
0.2C (3200mA) |
|
Max Continuous Discharge |
60A |
|
Peak Discharge Current |
100A (≤3 seconds) |
|
Discharge Cut-Off Voltage |
18V |
|
Dimensions |
192.5±5mm (L) x 76.5±1.5mm (W) x 62.5±2.5mm (H) |
|
Weight |
1770g |
|
Connectors |
XT90-S (discharge), JST-XHR-7P (charge) |
Cycle Life
|
Test Condition |
Cycles |
|
0.5C CC/CV charge to 25.2V, 60A discharge to 21V (Capacity ≥80% of initial) |
150 |
Operating Temperature Range
|
Operation |
Temperature Range |
Current Limit |
|
Charging |
10°C to 45°C |
≤0.5C (15°C–45°C) |
|
10°C to 15°C |
≤0.2C |
|
|
Discharging |
-20°C to 60°C |
≤0.2C (<10°C or >45°C) |
|
10°C to 45°C |
≤60A (recommended) |
Certifications
Complies with GB31241-2014/GB/T 18287-2013 (China National Standard).
Key Features
- High discharge rate (15C continuous, 100A peak).
- Low self-discharge (≥85% capacity after 28 days at 23°C).
- Waterproof design (non-immersion).
Applications
- Industrial drones
- Heavy-lift UAVs
- Long-endurance aerial photography
![]()
Usage Warnings & Precautions
- Do not reverse charge or exceed 25.2V.
- Avoid short circuits, mechanical shock, or piercing.
- Never disassemble or incinerate.
Storage Guidelines
- Short-term (≤7 days): 23.4V max, 23±5°C.
- Long-term (≥3 months): 22.5V–23.4V, 23±5°C, 65±20% RH.
- Activation: Every 3 months (0.2C charge/discharge cycle).
Warranty & Disclaimer
- Performance warranties void if misused or modified.
- Not responsible for accidents due to improper handling.
