3.7V 280mAh Lipo Battery 500 Cycles 1C Discharge OiD651533-280
OiD651533-280 Lithium Polymer Battery 3.7V 280mAh 1C Discharge 500 Cycles
Product Name
OiD651533-280 Lithium Polymer Battery
Advantages
- High energy density
- Long cycle life
- Lightweight and compact design
- Safe and reliable performance
Specifications
|
Parameter |
Value |
|
Nominal Voltage |
3.7V |
|
Minimum Capacity |
275mAh (0.2C discharge) |
|
Typical Capacity |
280mAh (0.2C discharge) |
|
Charging Voltage |
4.2V |
|
Discharging Cut-off Voltage |
3.0V |
|
Standard Charging |
0.2C/4.2V |
|
Max Charging |
1.0C/4.2V |
|
Standard Discharging |
0.2C/3.0V |
|
Max Discharging |
1.0C/3.0V |
|
Weight |
Approx. 5.0g |
|
Shipment Voltage |
3.90±0.05V |
|
Battery Pack Impedance |
≤300mΩ |
|
Terminal Type |
Tab |
|
Terminal Material |
Nickel |
Cycle Life
|
Condition |
Cycles |
Capacity Retention |
|
0.2C Charge/Discharge at 23±2℃ |
500 |
≥80% |
Discharge Curve
Operating Temperature Range
|
Condition |
Temperature Range |
|
Charging |
0℃ ~ 45℃ |
|
Max Charging Current (0℃ ~ 10℃) |
0.2C max |
|
Max Charging Current (10℃ ~ 20℃) |
0.5C max |
|
Max Charging Current (20℃ ~ 45℃) |
1.0C max |
|
Discharging |
-20℃ ~ 60℃ |
|
Max Discharging Current (-20℃ ~ 0℃) |
0.2C max |
|
Max Discharging Current (0℃ ~ 25℃) |
0.5C max |
|
Max Discharging Current (25℃ ~ 60℃) |
1.0C max |
|
Storage (50% SOC) |
-10℃ ~ 25℃ (12 months, ≥85%) |
|
Storage (50% SOC) |
-10℃ ~ 45℃ (6 months, ≥85%) |
|
Storage (50% SOC) |
-10℃ ~ 55℃ (1 month, ≥90%) |
Certifications
- RoHS compliant
- UL1642 certified
- IEC/EN61960 compliant
- GB/T 18287-2013 compliant
Key Features
- High discharge rate capability
- Excellent low-temperature performance
- Built-in protection circuit for overcharge, over-discharge, and short-circuit protection
- Environmentally friendly and recyclable
Applications
- Wearable devices
- Medical devices
- IoT devices
- Portable electronics
- Smart home devices
Usage Warnings & Precautions
- Do not short-circuit the battery terminals.
- Avoid exposing the battery to high temperatures or direct sunlight.
- Use only the specified charger for charging.
- Do not disassemble or modify the battery.
- Keep the battery away from children and pets.
Storage Guidelines
- Store the battery at 20±5℃ for optimal performance.
- If storing for more than 3 months, charge the battery to 60% capacity every 3 months.
- Avoid storing the battery in humid or high-temperature environments.
Warranty & Disclaimer
- 12-month warranty from the date of shipment.
- The warranty does not cover damage caused by improper use, mishandling, or unauthorized modifications.
- The manufacturer is not responsible for any accidents or damages resulting from the misuse of the battery.
