3.7V 2000mAh Rechargeable Lipo Battery 500 Cycles 1.5A Discharge
OiD684261C-2000 Lithium Polymer Battery 3.7V 2000mAh 1.5A Discharge Current 500 Cycles
Product Name:
OiD684261C-2000 Lithium Polymer Battery
Advantages:
- High energy density for extended usage
- Long cycle life with reliable performance
- Compact and lightweight design
- Built-in protection circuit for enhanced safety
Specifications:
|
Parameter |
Value |
|
Model |
OiD684261C-2000 |
|
Nominal Voltage |
3.7V |
|
Minimum Capacity |
1900mAh (0.2C discharge) |
|
Typical Capacity |
2000mAh (0.2C discharge) |
|
Charging Voltage |
4.2V |
|
Discharge Cut-off Voltage |
3.0V |
|
Standard Charging Current |
400mA |
|
Max Charging Current |
1500mA (20°C~45°C), 0.5C (10°C~20°C), 0.2C (0°C~10°C) |
|
Standard Discharging Current |
400mA |
|
Max Discharging Current |
1500mA (25°C~60°C), 0.5C (0°C~25°C), 0.2C (-20°C~0°C) |
|
Weight |
Approx. 36.0g |
|
Shipment Voltage |
3.90±0.05V |
|
Battery Impedance |
≤200mΩ |
|
Connector |
JST ZHR-3P, JCTC Housing: 11501H00-3P-HF, Contact: 11501TOP-2E-NK |
Cycle Life:
|
Condition |
Performance |
|
Charge/Discharge Cycles |
500 cycles at 0.2C, 23±2℃ |
|
Capacity Retention |
≥80% |
Discharge Curve:
Operating Temperature Range:
|
Condition |
Temperature Range |
|
Charging |
0°C ~ 45°C |
|
Discharging |
-20°C ~ 60°C |
|
Storage (50% SOC) |
-10°C ~ 25°C (12 months, ≥85%), -10°C ~ 45°C (6 months, ≥85%), -10°C ~ 55°C (1 month, ≥90%) |
Certifications:
- Compliant with GB/T 18287-2013, IEC/EN61960, UL1642 standards
Key Features:
- Overcharge, over-discharge, and short-circuit protection
- High-temperature and low-temperature performance
- RoHS compliant
Applications:
- Portable electronic devices
- Medical devices
- IoT devices
- Wearable technology
- Power banks
Usage Warnings & Precautions:
- Avoid overcharging or over-discharging the battery.
- Do not expose the battery to extreme temperatures or direct sunlight.
- Use only compatible chargers and devices.
- Do not disassemble or puncture the battery.
Storage Guidelines:
- Store at 20±5°C for optimal performance.
- Maintain a state of charge (SOC) of 50% for long-term storage.
- Avoid storing in high humidity or corrosive environments.
Warranty & Disclaimer:
- 12-month limited warranty against manufacturing defects.
- The manufacturer is not liable for damages caused by improper use or handling.
